Goodrive350-19 series VFD for crane
Function
Name
code
P16.49 Sent PZD8 6: Actual output torque (x10, %)
P16.50 Sent PZD9
P16.51 Sent PZD10
P16.52 Sent PZD11
P16.53 Sent PZD12
7: Actual output power (x10, %)
8: Rotation speed of running (x1, RPM)
9: Linear speed of running (x1, m/s)
10: Ramp reference frequency
11: Fault code
12: AI1 input (* 100, V)
13: AI2 input (* 100, V)
14: AI3 input (* 100, V)
15: HDIA frequency value (*100, kHz)
16: Terminal input status
17: Terminal output status
18: PID reference (x100, %)
19: PID feedback (x100, %)
20: Motor rated torque
21: High-order bit of position reference (signed)
22: Low-order bit of position reference (unsigned)
23: High-order bit of position feedback (signed)
24: Low-order bit of position feedback (unsigned)
25: Status word
26: HDIB frquency value (*100, kHz)
27: Pulse count high-order bits
28: Pulse count low-order bits
29: Brake status
30–51: Reserved
52: Temperature
53: U-phase current transient value
54: V-phase current transient value
55: W-phase current transient value
56–57: Reserved
58: Load weight
59: Current peak value
60: Filter torque setting (filter after running)
61: Mwh electromotive status (high-order bits)
62: Kwh electromotive status (low-order bits) (*10, Kwh)
63: Mwh electricity generation status (high-order bits)
64: Kwh electricity generation status (low-order bits) (*10, Kwh)
-433-
CW and SW module for port crane applications
Description
