Goodrive350-19 series VFD for crane
Function
Name
code
Setting source of
braking torque
P03.19
upper limit
Electromotive
torque upper limit
P03.20 set through
keypad
Braking torque
upper limit set
P03.21
through keypad
Weakening
coefficient in
P03.22
constant power
zone
Lowest
weakening point
P03.23
in constant power
zone
Description
5: Modbus communication
6: PROFIBUS/CANopen/DeviceNet
communication
7: Ethernet communication
8: Pulse frequency HDIB (100% corresponding
to triple the motor rated current)
9: EtherCAT/Profinet communication
10: Programmable expansion card
11: 216 communication
0: Keypad (P03.21)
1–11: Same as those for P03.18
0.0–300.0% (of the motor rated current)
Note: It can be modified only when P11.26=1
indicating special functions are enabled.
Used when the AM is in flux-weakening control.
T
Min. flux-weakening limit of motor
The function codes P03.22
at constant power. The motor enters the
flux-weakening state when the motor runs above
the rated speed. Change the flux-weakening
curvature by modifying the flux-weakening
control coefficient. The larger the coefficient, the
steeper the curve, the smaller the coefficient, the
-223-
Flux-weakening
coefficient of motor
0.1
1.0
2.0
f
and P03.23 are valid
Function parameter list
Default Modify
○
0
○
250.0%
○
250.0%
○
0.3
○
20%
