Goodrive350-19 series VFD for crane
Fault
Fault type
code
CAN
master/slave card
SECAN
communication
timeout fault
Master/slave
S-Err
synchronous
CAN slave fault
dIS
VFD disabled
Contactor
tbE
feedback fault
Brake feedback
FAE
Torque
tPF
verification fault
Operating lever
StC
zero-position fault
Low-speed run
LSP
protection fault
Terminal
tCE
command
exception
Power on
POE
Terminal
command
Possible cause
There is no data transmission
between the CAN master and
slave communication cards.
Fault occurred to one of the
CAN slave VFDs.
The input terminal selects VFD
enabling, but the terminal signal
is invalid.
The contactor feedback circuit
is disconnected or in poor
contact.
The contactor feedback
detection time is too short.
The brake feedback circuit is
disconnected or in poor contact.
fault
The brake feedback detection
time is too short.
The torque verification current,
moment force setting, and
torque verification fault
detection time are set
improperly.
The operating lever does not
return to the zero position.
The operating lever
zero-position signal is adhered.
Running speed too low.
The terminal gives both the
upward and downward
commands at the same time.
The terminal command is
detected at power-on.
Check whether the
communication card wiring is
loose or dropped.
Detect the CAN slave VFD and
analyze the corresponding fault
cause.
Check the input terminal setting
and terminal signal.
Check the contactor feedback
circuit.
Increase the detection time
P91.05
Check the brake feedback circuit.
Increase the detection time
P90.32
Set the torque verification current,
moment force setting, and torque
verification fault detection time
P90.30
Check whether the motor rated
power is set correctly.
Put the operating lever to the zero
position.
Check out the operating lever
zero-position signal.
Check whether the running speed
is continuously lower than P92.03.
Check the input terminal signal.
Check whether
enable the VFD reports a fault
when a terminal command is valid
-383-
Troubleshooting
Solution
to a proper value.
to a proper value.
properly.
P01.18
is set to
