INVT Goodrive350-19 Series Operation Manual page 178

Goodrive350-19 series VFD for crane
Function
code
P01.23
P01.24 Stop speed delay
Open-loop 0Hz output
P01.25
DEC time for emergency
P01.26
Time of starting segment of
P01.27
Time of ending segment of
P01.28
P01.29 Short-circuit braking current 0.0–150.0% (of the VFD rated current)
Hold time of short-circuit
P01.30
braking for start
Hold time of short-circuit
P01.31
braking for stop
P05.01–P Digital input function
05.06
P08.00
P08.01
P08.02
P08.03
P08.04
Name
Start delay
selection
stop
DEC S curve
DEC S curve
selection
ACC time 2
DEC time 2
ACC time 3
DEC time 3
ACC time 4
Description
0.0–60.0s
0.0–100.0s
0: Output without voltage
1: Output with voltage
2: Output with the DC braking current for
stop
0.0–60.0s
0.0–50.0s
0.0–50.0s
0.00–50.00s
0.00–50.00s
1: Run forward
2: Run reversely
4: Jog forward
5: Jog reversely
6: Coast to stop
7: Reset faults
8: Pause running
21: ACC/DEC time selection 1
22: ACC/DEC time selection 2
30: Disable ACC/DEC
0.0–3600.0s
0.0–3600.0s
0.0–3600.0s
0.0–3600.0s
0.0–3600.0s
-166-
Basic operation guidelines
Default
0.0s
0.0s
0
2.0s
0.1s
0.1s
0.0%
0.00s
0.00s
Model
depended
Model
depended
Model
depended
Model
depended
Model
depended
