INVT Goodrive350-19 Series Operation Manual page 300

Goodrive350-19 series VFD for crane
Function
Name
code
P17.08 Motor power
Motor output
P17.09
torque
Estimated motor
P17.10
frequency
P17.11 DC bus voltage
Digital input
P17.12
terminal status
Digital output
P17.13
terminal status
Digital adjustment
P17.14
value
Torque reference
P17.15
value
Description
Range: -3000.0–3000.0A
Displays the present motor power; 100% relative
to the rated motor power. The positive value is
the motoring state while the negative value is
the generating state.
Range: -300.0–300.0% (relative to the rated
motor power)
Displays the present output torque of the VFD;
100% relative to the rated motor torque. During
forward running, the positive value is the
motoring state while the negative value is
generating state. During reverse running, the
positive value is the generating state while the
negative value is the motoring state.
Range: -250.0–250.0%
Displays the estimated motor rotor frequency
under the open-loop vector condition.
Range: 0.00–P00.03
Displays the present DC bus voltage of the VFD.
Range: 0.0–2000.0 V
Displays the present digital input terminal state
of the VFD.
0x00–0x3F
Corresponds to HDIB, HDIA, S4, S3, S2 and S1
respectively.
Displays the present digital output terminal state
of the VFD.
0x0–0xF
Corresponds to RO2, RO1, HDO and Y1
respectively
Displays the adjustment on the VFD through the
UP/DOWN terminal.
Range: 0.00Hz–P00.03
Relative to the percentage of the rated torque of
the present motor, displaying the torque
reference.
Range: -300.0%–300.0% (of the motor rated
current)
-288-
Function parameter list
Default Modify
●
0.0%
●
0.0%
●
0.00Hz
●
0V
●
0
●
0
●
0.00Hz
●
0.0%
