INVT Goodrive350-19 Series Operation Manual page 123

Goodrive350-19 series VFD for crane
User-defined
function
function
A81.35
A81.36
A81.37
A81.38
A81.39
A81.40
A81.41
A81.42
A81.43
A81.44
A82.00–A82.44 With the same functions as A81.00–A81.44
A83.00–A83.44 With the same functions as A81.00–A81.44
Related
Name
code
release torque motor rated torque)
Reverse brake
P90.15
release torque
Forward brake
P90.16 release
frequency
Reverse brake
P90.17 release
frequency
Forward brake
P90.18 closing
frequency
Reverse brake
P90.19 closing
frequency
Delay before
P90.20 forward brake
release
Delay after
P90.22 forward brake
release
Delay before
P90.24 forward brake
closing
Delay after
P90.26 forward brake
closing
Enabling the
P90.31 monitoring on
brake status
Description
0.0–200.0% (of the
motor rated torque)
0.00–20.00Hz
0.00–20.00Hz
0.00–20.00Hz
0.00–20.00Hz
0.000–5.000s
0.000–5.000s
0.000–5.000s
0.000–5.000s
0–1
0: Disable
1: Enable the brake
current monitoring (and
brake feedback
detection).
-111-
Commissioning guidelines
Setting
Default
range
0.0–200.0 0.0%
0.00–20.00 3.00Hz
0.00–20.00 3.00Hz
0.00–20.00 3.00Hz
0.00–20.00 3.00Hz
0.000–5.000 0.300s
0.000–5.000 0.300s
0.000–5.000 0.300s
0.000–5.000 0.300s
0–1 0
