Goodrive350-19 series VFD for crane
H1 H2
Outline Dimensions (mm)
VFD model
90kW–110kW
H1
Outline Dimensions (mm)
VFD model
132kW–200kW
W1
W2
Figure C-8 380V 90–110kW wall mounting diagram
W1 H1 D1
338 554 330
W1
Figure C-9 380V 132–200kW wall mounting diagram
W1 H1 D1
500 870 360
Hole distance
Hole
(mm)
diameter
(mm)
W2 H2
200 535
D1
Hole distance
Hole
(mm)
diameter
(mm)
W2 H2
180 850
-479-
Dimension drawings
D1
Net
Screw weight
(kg)
10 M8 41
W2 W2
6- ø11.0
H2
Net
Screw weight
(kg)
11 M10 85
Gross
weight
(kg)
52
Gross
weight
(kg)
110
