INVT Goodrive350-19 Series Operation Manual page 121

Goodrive350-19 series VFD for crane
User-defined
function
function
A81.16
A81.17
A81.18
A81.19
A81.20
A81.21
A81.22
A81.23
A81.24
A81.25
A81.26
Related
Name
code
Multi-step speed
P10.02
0
Multi-step speed
P10.04
1
Multi-step speed
P10.06
2
Multi-step speed
P10.08
3
Multi-step speed
P10.10
4
P25.01 Function of S5
P25.02 Function of S6
P25.03 Function of S7
Master/slave
P28.00
mode
Enabling
P90.04 brake-oriented
logic
Enabling forward
torque for
P90.05
reverse-running
start/stop
Description
0.0–100.0%
0.0–100.0%
0.0–100.0%
0.0–100.0%
0.0–100.0%
Same as P5
0: The master/slave
mode is invalid.
1: The local device is the
master.
2: The local device is the
slave.
0–1
0: The brake is
controlled by an external
controller.
1: The brake is
controlled by the VFD.
0x00–0x11
Ones place: indicates
whether to enable
forward torque for
reverse-running start
0: Disable
(The reverse-running
start direction complies
with the command.)
1: Enable
(The reverse-running
-109-
Commissioning guidelines
Setting
Default
range
0.0–100.0 0.0%
0.0–100.0 0.0%
0.0–100.0 0.0%
0.0–100.0 0.0%
0.0–100.0 0.0%
0–90 0
0–90 0
0–90 0
0–2 0
0–1 0
0x00–0x11 0x00
