Goodrive350-19 series VFD for crane
LED
(Maintenance status
indicator)
LED6/7
(Network port status
indicator)
LED8/9
(Network port
communication
indicator)
Electrical connection:
The PROFINET communication card adopts standard RJ45 interfaces, which can be used in a linear
network topology and a star network topology. The linear network topology electrical connection
diagram is shown in the following.
Master
device
Figure A-5 Linear network topology electrical connection diagram
Note: For the star network topology, you need to prepare PROFINET switches.
The star network topology electrical connection diagram is shown as follows.
Master
device
Color Status
On
Green
Off
On
Green
Off
Slave device 1 Slave device 2
RJ45 RJ45
RJ45
Slave device 1 Slave device 2
RJ45 RJ45
RJ45
Switch
characteristics of the device
PROFINET communication card and PC/PLC
have been connected with a network cable.
PROFINET communication card and PC/PLC
have not been connected yet.
PROFINET communication card and PC/PLC
are communicating.
PROFINET communication card and PC/PLC
are not yet communicating.
RJ45
RJ45
-452-
Expansion card
Description
Slave device n
RJ45
RJ45
Slave device n
RJ45
RJ45
