INVT Goodrive350-19 Series Operation Manual page 160

Goodrive350-19 series VFD for crane
Function
code
frequency
P00.11 ACC time 1
P00.12 DEC time 1
P02.00 Type of motor 1
Rated frequency of
P02.02
P02.04 Rated voltage of AM 1 0–1200V
V/F curve setting of
P04.00
motor 1
Torque boost of motor
P04.01
Torque boost cut-off
P04.02
of motor 1
V/F frequency point 1
P04.03
of motor 1
V/F voltage point 1 of
P04.04
motor 1
V/F frequency point 2
P04.05
of motor 1
V/F voltage point 2 of
P04.06
motor 1
V/F frequency point 3
P04.07
of motor 1
V/F voltage point 3 of
P04.08
motor 1
V/F slip compensation
P04.09
gain of motor 1
Low-frequency
P04.10
oscillation control
Name
0.0–3600.0s
0.0–3600.0s
0: Asynchronous motor (AM)
1: Synchronous motor (SM)
0.01Hz–P00.03 (Max. output frequency)
AM 1
0: Straight-line V/F curve
1: Multi-point V/F curve
2: Torque-down V/F curve (power of 1.3)
3: Torque-down V/F curve (power of 1.7)
4: Torque-down V/F curve (power of 2.0)
5: Customized V/F curve (V/F separation)
0.0%: (automatic)
1 0.1%–10.0%
0.0%–50.0% (of the rated frequency of motor 1)
0.00Hz–P04.05
0.0%–110.0%
P04.03–P04.07
0.0%–110.0%
P04.05–P02.02 or P04.05–P02.16
0.0%–110.0%
0.0–200.0%
0–100
Description
-148-
Basic operation guidelines
Default
Model
depended
Model
depended
0
50.00Hz
Model
depended
0
0.0%
20.0%
0.00Hz
0.0%
0.00Hz
0.0%
0.00Hz
0.0%
100.0%
10
