Goodrive350-19 series VFD for crane
VFD model
GD350-19-075G-6
GD350-19-090G-6
GD350-19-110G-6
GD350-19-132G-6
GD350-19-160G-6
GD350-19-185G-6
GD350-19-200G-6
GD350-19-220G-6
GD350-19-250G-6
GD350-19-280G-6
GD350-19-315G-6
GD350-19-355G-6
GD350-19-400G-6
GD350-19-450G-6
GD350-19-500G-6
GD350-19-560G-6
GD350-19-630G-6
Note: The accessory specifications described in the preceding table are ideal values. You can
select accessories based on the actual market conditions, but try not to use those with lower
values.
D.7 Reactor
When the voltage of the grid is high, the transient large current that flows into the input power circuit
may damage rectifier components. You need to configure an AC reactor on the input side, which can
also improve the current adjustment coefficient on the input side.
When the distance between the VFD and motor is longer than 50 m, the parasitic capacitance
between the long cable and ground may cause large leakage current, and overcurrent protection of
the VFD may be frequently triggered. To prevent this from happening and avoid damage to the motor
insulator, compensation must be made by adding an output reactor. When a VFD is used to drive
multiple motors, take the total length of the motor cables (that is, sum of the lengths of the motor
cables) into account. When the total length is longer than 50 m, an output reactor must be added on
the output side of the VFD. If the distance between the VFD and motor is 50 m to 100 m, select the
reactor according to the following table. If the distance is longer than 100 m, contact INVT's technical
support technicians.
DC reactors can be directly connected to 380V 132kW and higher models and all 660V models. DC
Fuse (A) Braker (A)
270 200
270 200
315 200
420 250
480 315
480 315
630 400
720 400
720 400
870 630
1110 630
1110 630
1230 800
1470 960
1500 1000
1740 1200
2010 1380
-496-
Optional peripheral accessories
Contactor rated current (A)
135
135
170
230
280
280
315
380
380
450
580
580
630
735
780
900
1035
