P17 Group--Status Viewing - INVT Goodrive350-19 Series Operation Manual

Goodrive350-19 series VFD for crane
Function
Name
code
expansion card in
card slot 2
Time to identify
P16.26 expansion card in
card slot 3
Communication
P16.27 timeout period of
card at slot 1
Communication
P16.28 timeout period of
card at slot 2
Communication
P16.29 timeout period of
card at slot 3
P16.30–
See Goodrive350 series VFD communication expansion card manual for details.
P16.69
P17 group––Status viewing
Function
Name
code
P17.00 Set frequency
P17.01 Output frequency
Ramp reference
P17.02
frequency
P17.03 Output voltage
P17.04 Output current
Motor rotation
P17.05
speed
P17.06 Torque current
P17.07 Exciting current Displays the present exciting current of the VFD.
Description
The value 0.0 indicates that identification fault
will not be detected.
0.0–600.0s
The value 0.0 indicates that identification fault
will not be detected.
0.0–600.0s
The value 0.0 indicates offline fault will not be
detected.
0.0–600.0s
The value 0.0 indicates offline fault will not be
detected.
0.0–600.0s
The value 0.0 indicates offline fault will not be
detected.
Description
Displays the present set frequency of the VFD.
Range: 0.00Hz–P00.03
Displays the present output frequency of the
VFD.
Range: 0.00Hz–P00.03
Displays the present ramp reference frequency
of the VFD.
Range: 0.00Hz–P00.03
Displays the present output voltage of the VFD.
Range: 0–1200V
Displays the valid value of current output current
of the VFD.
Range: 0.0–5000.0A
Displays the current motor speed.
Range: 0–65535RPM
Displays the present torque current of the VFD.
Range: -3000.0–3000.0A
-287-
Function parameter list
Default Modify
○
0.0s
○
0.0s
○
0.0s
○
0.0s
Default Modify
●
50.00Hz
●
0.00Hz
●
0.00Hz
●
0V
●
0.0A
●
0 RPM
●
0.0A
●
0.0A
