Goodrive350-19 series VFD for crane
Function
code
Reference object of B
P00.08
frequency command
Combination mode of setting
P00.09
Function selection of
P05.01–P multifunction digital input
05.06 terminals (S1–S4, HDIA,
UP/DOWN terminal control
P08.44
Frequency increment change
P08.45
rate of the UP terminal
P08.46 Frequency reduce rate of the 0.01–50.00Hz/s
Name
16: 216 communication
0: Max. output frequency
1: A frequency command
0: A
1: B
2: (A+B)
source 3: (A-B)
4: Max(A, B)
5: Min(A, B)
10: Increase frequency setting (UP)
11: Decrease frequency setting (DOWN)
12: Clear the frequency increase/decrease
setting
13: Switch between A setting and B setting
14: Switch between combination setting
HDIB)
and A setting
15: Switch between combination setting
and B setting
0x000–0x221
Ones place: Frequency setting selection
0: The setting made through UP/DOWN is
valid.
1: The setting made through UP/DOWN is
invalid.
Tens place: Frequency control selection
0: Valid only when P00.06=0 or P00.07=0
1: Valid for all frequency setting methods
setting
2: Invalid for multi-step speed running
when multi-step speed running has the
priority
Hundreds place: Action selection for stop
0: Setting is valid.
1: Valid during running, cleared after stop
2: Valid during running, cleared after a stop
command is received
0.01–50.00Hz/s
Description
-170-
Basic operation guidelines
Default
0
0
0x000
0.50 Hz/s
0.50 Hz/s
