INVT Goodrive350-19 Series Operation Manual page 120

Goodrive350-19 series VFD for crane
User-defined
function
function
A81.01
A81.02
A81.03
A81.04
A81.05
A81.06
A81.07
A81.08
A81.09
A81.10
A81.11
A81.12
A81.13
A81.14
A81.15
Related
Name
code
Channel of
P00.01 running
commands
Setting channel
P00.06 of A frequency
command
P00.11 ACC time 1
P00.12 DEC time 1
P01.05 ACC/DEC mode
P01.08 Stop mode
Enabling torque
P03.32
control
Enabling I/F
P04.40
mode for AM 1
Forward current
P04.41 setting in I/F
mode for AM 1
Reverse current
P04.52 setting in I/F
mode for AM 1
P05.03 Function of S3 0: No function
P05.04 Function of S4
P06.01 Y1 output
P06.03 RO1 output
P06.04 RO2 output
Description
1: Sensorless vector
control (SVC) mode 1
2: V/F control
3: Closed-loop vector
control mode
0: Keypad
1: Terminal
2: Communication
0: Keypad
1–14: See chapter 7.
15: Multi-step speed run
0.0–3600.0s
0.0–3600.0s
0: Linear
1: S curve
0: Decelerate to stop
1: Coast to stop
0: Disable
1: Enable
0–1
0.0–200.0%
0.0–200.0%
1: Run forward
2: Run reversely
3–90: See chapter 7.
0: Invalid
1: Running
2: Running forward
3: Running reversely
4–64: See chapter 7.
-108-
Commissioning guidelines
Setting
Default
range
0–2 0
0–15 0
0.0–3600.0 10.0s
0.0–3600.0 10.0s
0–1 0
0–1 0
0–1 0
0–1 0
0.0–200.0% 120.0%
0.0–200.0% 120.0%
0–90 0
0–90 0
0–64 0
0–64 0
0–64 0
