Goodrive350-19 series VFD for crane
Note: The value of P28.00 of VFD 1 needs to be modified through the PLC.
At the work conditions of trolley run, if it is difficult to change VFD 1 from master/slave control
mode to non master/slave control mode (P28.00=0) through the PLC, you can set the
hundreds place of P28.02 to 1 for VFD 1.
Parameters of VFD 2
Function
code
Function of S1
P05.01
Hoisting application
P90.00
macro setting
Terminal-switched
application macro
P90.01
Method for terminals to
switch application
P90.03
Master/slave mode
A81.24

5.14.5 User-defined application macros

You can enter user-defined application macro settings through P90.02.
Function
code
User-defined
P90.02 application macro
When P90.02=1, you will automatically enter A80.00–A80.41 to set related function codes.
When P90.02=2, you will automatically enter A81.00–A81.41 to set related function codes.
When P90.02=3, you will automatically enter A82.00–A82.41 to set related function codes.
Currently, there are 45 common function codes available for you to define macros. The three
user-defined macro tables are the same. The following lists A81.00–A81.41.
User-defined
function
function
A81.00
Name
35: Switch from motor 1 to motor 2
6: User-defined application macro 1
7: User-defined application macro 2
setting
1: Switch from motor 1 to motor 2
macros
2: The local device is the slave.
Name
0–3
0: None
1: Enter the settings of user-defined application
macro 1
2: Enter the settings of user-defined application
setting
macro 2
3: Enter the settings of user-defined application
macro 3
Related
Name
code
Speed control
P00.00
mode
Description
Description
Description
0: Sensorless vector
control (SVC) mode 0
-107-
Commissioning guidelines
Setting
35
6
7
1
2
Default
0
Setting
Default
range
0–3 2
