Goodrive350-19 series VFD for crane
Function
Name
code
AO1 output lower
P06.17
limit
AO1 output
P06.18 corresponding to
lower limit
AO1 output upper
P06.19
limit
P06.20 AO1 output
Description
PROFIBUS/CANopen/DeviceNet
communication (0–1000)
18: Value 1 set through Ethernet communication
(0–1000)
19: Value 2 set through Ethernet communication
(0–1000)
20: HDIB input (0.00–50.00kHz)
21: Value 1 set through EtherCAT/PROFINET
communication (0–1000)
22: Torque current (0–Triple the motor rated
current)
23: Exciting current (0–Triple the motor rated
current)
24: Set frequency (bipolar, 0–Max. output
frequency)
25: Ramp reference frequency (bipolar, 0–Max.
output frequency)
26: Rotational speed (bipolar, 0–Speed
corresponding to max. output frequency)
27: Value 2 set through EtherCAT/PROFINET
communication (0–1000)
28: C_AO1 from PLC (Set P27.00 to 1) (0–1000)
29: C_AO2 from PLC (Set P27.00 to 1) (0–1000)
30: Rotational speed (0–Twice the motor rated
synchronous speed)
31: Output torque (Actual value, 0–Twice the
motor rated torque)
32: Temperature measured by resistor
33: Value 1 set through 216 communication
34: Value 2 set through 216 communication
Used to define the relationship between the
output value and analog output. When the
output value exceeds the allowed range, the
output uses the lower limit or upper limit.
When the analog output is current output, 1mA
equals 0.5V.
In different cases, the corresponding analog
output of 100% of the output value is different.
-248-
Function parameter list
Default Modify
○
0.0%
○
0.00V
○
100.0%
○
10.00V
