INVT Goodrive350-19 Series Operation Manual page 345

Goodrive350-19 series VFD for crane
Function
Name
code
release
Delay before
P90.21 reverse brake
release
Delay after
P90.22 forward brake
release
Delay after
P90.23 reverse brake
release
Delay before
P90.24 forward brake
closing
Delay before
P90.25 reverse brake
closing
Delay after
P90.26 forward brake
closing
Delay after
P90.27 reverse brake
closing
Retaining
P90.28
frequency for stop
Retaining
P90.29 frequency hold
time for stop
Torque verification
P90.30 fault detection
time
Description
example:
Start: When the VFD is in standby state, the
brake output signal is closed. After receiving the
running command, the VFD accelerates with the
target frequency P90.16. In addition, the VFD
starts torque verification, if the verification is OK
(condition: output current>= P90.12) (it is
P90.13 in reverse running) and output torque >=
P90.14 (it is P90.15
frequency is at least equal to
P90.17 in reverse running), the delay before
forward brake release starts, and the VFD
outputs the brake release signal when
(or P90.21 in reverse running) is reached. Then
the delay after forward brake release starts. The
VFD normally accelerates to the set frequency
within the time specified by
reverse running).
Stop: To prevent hook slip, sufficient output
torque must be ensured before brake is closed.
After receiving the stop command, the VFD
decelerates to P90.28
frequency within P90.29. When output
frequency <= P90.18
running), the delay before brake release starts.
When the delay reaches
reverse running), the VFD outputs brake closing
signal. The delay after brake release starts. The
VFD decelerates to zero and stops within the
time P90.26 (or P90.27
P90.12, P90.13setting range: 0.0–200.0% (of
the motor rated current)
P90.14, 0.15 setting range: 0.0–200.0%(of the
motor rated current)
P90.16,90.17,P90.18,P90.19
0.00–20.00Hz
P90.20,P90.21,P90.22,P90.23,P90.24,P90.25,P
90.26,P90.27 setting range: 0.000–5.000s
-333-
in reverse running), output
P90.16 (it is
P90.20
P90.22 (or P90.23
with a maintenance
(or P90.19 in reverse
P90.24 (or P90.25
in reverse running).
setting range:
Function parameter list
Default Modify
0.000s
0.300s
0.000s
0.300s
0.000s
in
0.300s
0.000s
5.00Hz
in
0.000s
6.000s
○
○
○
○
○
○
○
○
○
○
