Goodrive350-19 series VFD for crane
Name
Profibus-DP
communication
card
Ethernet
communication
card
CANopen
communication
card
CAN
master/slave
control
communication
card
PROFINET
communication
card
Sin/Cos PG card
Incremental PG
card with UVW
Resolver PG
card
Multi-function
incremental PG
card
Model
applicable to molded case machines.
●EC-TX502-2 is configured with an external sucker antenna
and applicable to sheet metal machines.
●Supporting the PROFIBUS-DP protocol
EC-TX503
●Supporting Ethernet communication with INVT internal
protocol
EC-TX504
●Can be used in combination with INVT upper computer
monitoring software INVT Workshop
●Based on the CAN2.0A physical layer
EC-TX505
●Supporting the CANopen protocol
●Based on the CAN2.0B physical layer
EC-TX511
●Adopting INVT proprietary master/slave control protocol
●Supporting the PROFINET protocol
EC-TX509
●Applicable to Sin/Cos encoders with or without CD signals
●Supporting A, B, Z frequency-divided output
EC-PG502
●Supporting pulse string reference input
●Applicable to differential encoders of 5 V
●Supporting the orthogonal input of A, B, and Z
●Supporting pulse input of phases U, V, and W
EC-PG503-05
●Supporting frequency-divided output of A, B, and Z
●Supporting the input of pulse string reference
●Applicable to resolver encoders
●Supporting frequency-divided output of resolver-simulated A,
EC-PG504-00
B, Z
●Supporting the input of pulse string reference
●Applicable to OC encoders of 5V or 12V
●Applicable to push-pull encoders of 5V or 12V
●Applicable to differential encoders of 5V
EC-PG505-12
●Supporting the orthogonal input of A, B, and Z
●Supporting the frequency-divided output of A, B, and Z
Specifications
-437-
Expansion card
