Goodrive350-19 series VFD for crane
Function
Name
code
Torque limit 1 in
P90.41 open-loop vector
control
Torque setting for
P90.42
brake release
Brake closing
P90.44 delay after stop
DC braking starts
P91 group––Functions special for cranes
Function
Name
code
Enabling the
P91.00 conical motor
function
Conical motor
ACC process
P91.01
voltage coefficient
K1
Conical motor
constant process
P91.02
voltage coefficient
K2
Conical motor
DEC process
P91.03
voltage coefficient
K3
Description
Setting range: 0.0–300.0% (of the motor rated
current)
(P90.40=1 Torque limit mode)
0.0–200.0%
During the running, when the torque feedback
value is equal to or greater than P90.42, brake
release timing is entered.
(It is valid only when P90.04=1, which indicates
the brake is controlled by the VFD, and the VFD
uses the torque mode.)
0.00–50.00HZ
Used in torque/speed switchover mode 2
Description
The conical motor does not require external
braking since it implements braking by using
internal magnetic flux control. During start, the
starting frequency needs to be increased for
brake release. During stop, quick demagnetizing
needs to be implemented to prevent slip in case
of overdue brake closing.
P91.00 setting range: 0–1
0: Disable
1: Enable
P91.00=0: Disable. Normal voltage curves are
used.
P91.00=1: Conical motor voltage curves are
used.
P91.01 setting range: P91.02–150.0%
(100.0% corresponds to the motor rated
voltage.)
P91.02 setting range:
P91.03 setting range:
-339-
P91.03–P91.01
0.0–P91.02
Function parameter list
Default Modify
○
120.0%
○
50.0%
◎
8.00Hz
Default Modify
◎
0
○
120.0%
○
100.0%
○
80.0%
