INVT Goodrive350-19 Series Operation Manual page 310

Goodrive350-19 series VFD for crane
Function
Name
code
selection
Speed
P20.15 measurement
mode
Frequency
P20.16
division coefficient
Pulse filter
P20.17
handling selection
Description
0: without UVW
1: with UVW
Tens place: Sin/Cos encoder
0: without CD signal
1: with CD signal
0: Measuring speed by PG card/Measuring
height by HDI
1: Measuring locally through HDIA and HDIB.
Only the 24V incremental encoders are
supported.
24: Pulses are obtained through CANopen or
PROFIBUS-DP communication to measure the
speed.
24: Pulses are obtained through PROFINET
communication to measure the speed.
Note: HDI height measuring is implemented
through the HDIA and HDIB and supports
only incremental 24V encoders.
0–255
When the function parameter is set to 0 or 1,
frequency division of 1:1 is implemented.
0x0000–0xFFFF
Bit0: Enable/disable encoder input filter
0: No filter
1: Filter
Bit1: Encoder signal filter mode
0: Self-adaptive filter
1: Use P20.18 filter parameter
Bit2: Enable/disable encoder frequency-division
output filter
0: No filter
1: Filter
Bit3: Enable/disable pulse reference
frequency-division output filter
0: No filter
1: Filter
Bit4: Enable/disable pulse reference filter
0: No filter
-298-
Function parameter list
Default Modify
◎
0
○
0
○
0x0033
