  • Page 1 Goodrive300-16 Special Inver ter for HVAC...

  • Page 2: Preface

    Goodrive300-16 special inverter for HVAC Preface Preface Thanks for choosing our products. Goodrive300-16 special inverters for HVAC are developed according to HVAC application features and control requirements, and can be widely used in heating and water supply. Applying TI 32bit DSP control system and the most advanced international SVC technology, Goodrive300-16 inverters can meet the high performance requirements of customers.
  • Page 3 Goodrive300-16 special inverter for HVAC Content Content Preface ..........................1 Content ..........................2 Chapter 1 Safety precautions ..................... 3 1.1 What this chapter contains .................. 3 1.2 Safety definition ....................3 1.3 Warning symbols ....................3 1.4 Safety guidelines ....................4 Chapter 2 Product overview ....................

  • Page 4: Chapter 1 Safety Precautions

    Goodrive300-16 special inverter for HVAC Safety precautions Chapter 1 Safety precautions 1.1 What this chapter contains Please read this manual carefully and follow all safety precautions before moving, installing, operating and servicing the inverter. If ignored, physical injury or death may occur, or damage may occur to the devices.

  • Page 5: Safety Guidelines

    Goodrive300-16 special inverter for HVAC Safety precautions Symbols Name Instruction Abbreviation Damage to the PCBA board may Electrostatic occur if not follow the relative Do not discharge requirements Sides of the device may become Hot sides hot. Do not touch. Hot sides Physical hurt may occur if not follow Note...
  • Page 6 Goodrive300-16 special inverter for HVAC Safety precautions  Do not touch the inverter with wet items or body, otherwise electric shock may occur. Note:  Select appropriate moving and installing tools to ensure a safe and normal running of the inverter and avoid physical injury or death. For physical safety, the erector should take some mechanical protective measures, such as wearing exposure shoes and working uniforms.
  • Page 7 Goodrive300-16 special inverter for HVAC Safety precautions Note:  Do not switch on or off the input power supply of the inverter frequently.  For inverters that have been stored for a long time, check and fix the capacitance and try to run it again before utilization (see Maintenance and Hardware Fault Diagnose).

  • Page 8: Chapter 2 Product Overview

    Goodrive300-16 special inverter for HVAC Product overview Chapter 2 Product overview Goodrive300-16 are special inverters for HVAC designed to solve the application problems in HVAC industry, reduce the costs of customers, enhance the competitiveness and guarantee for the advantages in HVAC industry. The products possess following features: 1.
  • Page 9 Goodrive300-16 special inverter for HVAC Product overview Function Specification PID function 2 sets of PID G type: 150% of rated current: 60 seconds 180% of rated current: 10 seconds Overload capability 200% of rated current: 1 second P type: 120% of rated current: 60 seconds Starting torque 0.3Hz 150% (sensorless vector control) More than 30 protection functions, including...

  • Page 10: Name Plate

    Goodrive300-16 special inverter for HVAC Product overview Function Specification Selectable C2 filters: meet the degree requirement of IEC61800-3 C2 2.2 Name plate Fig 2-1 Name plate Note: The name plate above is an example of Goodrive300-16 standard products. CE/TUV/IP20 will be identified on basis of actual certification. 2.3 Type designation key The type designation contains information on the inverter.

  • Page 11: Rated Specifications

    Goodrive300-16 special inverter for HVAC Product overview S2: AC 1PH 220V(-15%)~240V(+10%) 2: AC 3PH 220V(-15%)~240V(+10%) Voltage ③ Voltage degree 4: AC 3PH 380V(-15%)~440V(+10%) degree 6: AC 3PH 520V(-15%)~690V(+10%) Protective degree (the protective degree of standard products can be default) 0-IP00; ④...

  • Page 12: Chapter 3 Commissioning Guidelines

    Goodrive300-16 special inverter for HVAC Commissioning guidelines Chapter 3 Commissioning guidelines 3.1 Wiring of main circuit Braking resistor Single-phase 220V optional Output reactor Input Three-phase reactor 380V(-15%) Inverters (≤30kW) Output ~440V(+10%) filter Input 50/60Hz filter Fuse Braking unit DC reactor Braking resistor Single-phase 220V optional Output...

  • Page 13: Terminals Of Control Circuit

    Goodrive300-16 special inverter for HVAC Commissioning guidelines Terminal name Terminal Function ≤75kW ≥90kW unit terminal 1 PB and (+) are connected with the terminals of braking resistor. Braking unit terminal 2 Braking resistor 2 Protective grounding terminals, every machine 380V: the grounding resistor is is provided 2 PE terminals as the standard less than 10Ω...
  • Page 14 Goodrive300-16 special inverter for HVAC Commissioning guidelines Type Code Terminal name Description Provide the input switch working External power power supply from external to supply internal. Voltage range: 12~24V Analog input 1 1. Input range: AI1/AI2 voltage and current can be chosen Analog input 2 0~10V/0~20mA;...
  • Page 15 Goodrive300-16 special inverter for HVAC Commissioning guidelines Type Code Terminal name Description 2. Output frequency range: 0~50kHz 1. Switch capacity: 50mA/30V Switch output 2. Output frequency range: 0~1kHz 485 communication terminal, adopt Communication 485+,485- communication MODBUS protocol RO1A Relay 1 NO contact RO1B Relay 1 NC contact Relay 1 common...

  • Page 16: Wiring And Commissioning Of Single Fixed Variable Frequency Motor+Multiple Power Frequency Motors

    Goodrive300-16 special inverter for HVAC Commissioning guidelines 3.3 Wiring and commissioning of single fixed variable frequency motor+multiple power frequency motors 3.3.1 Standard wiring diagram GD300-16 +10V PID1 reference PID1 feedback L1/L2/L3 Note: The diagram is the system of the fixed variable frequency motor+3 power frequency motors, which will become the system of single variable frequency motor without connecting power frequency motors.
  • Page 17 Goodrive300-16 special inverter for HVAC Commissioning guidelines 3.3.3 List of control parameters List of relevant function parameters (take 3 power frequency motors for example) Function Name Remark code value P00.00 Speed control mode V/F control Run command Terminal control, adjustable according to P00.01 channel the actual situations...
  • Page 18 Goodrive300-16 special inverter for HVAC Commissioning guidelines Function Name Remark code value PID1 reference situations PID1 feedback Adjustable according to the actual P09.10 source 1 situations Adjustable according to the actual P09.16 Output feature situations Adjustable according to the actual P09.17 Proportional gain 1.00...
  • Page 19 Goodrive300-16 special inverter for HVAC Commissioning guidelines Function Name Remark code value runs continuously when the running frequency reaches the upper limit while the feedback cannot reach the set value after boost, the inverter will enter hibernation immediately after boost time. PID output directly starts superposition Hibernation waking P22.07...
  • Page 20 Goodrive300-16 special inverter for HVAC Commissioning guidelines Function Name Remark code value Running frequency Adjustable according to the actual P22.20 50.00Hz when adding motor situations Delay time when Adjustable according to the actual P22.21 10.0s adding motor situations Pressure allowance Adjustable according to the actual P22.24 4.0%...
  • Page 21 Goodrive300-16 special inverter for HVAC Commissioning guidelines 3.3.4 Instruction of commissioning process 1. If the system of single variable frequency motor does not need the auxiliary power frequency motor, set P22.11, P22.12 and P22.13 to 0. The system will proceed with close loop PID adjustment, control the output frequency of the inverter and support P22.01 to hibernate and wake up.

  • Page 22: Wiring And Commissioning Of Multiple Circulation Variable Frequency Motors+Multiple Power Frequency Motors

    Goodrive300-16 special inverter for HVAC Commissioning guidelines 3.4 Wiring and commissioning of multiple circulation variable frequency motors+multiple power frequency motors 3.4.1 Standard wiring diagram GD300-16 +10V PID1 reference PID1 feedback L1/L2/L3 KM0 KM1 KM2 KM3 KM4 KM5 Note: The diagram is the system of 3 circulation variable frequency motors+2 power frequency motors, which will become the system of 3 circulation variable frequency motors without connecting power frequency motors.
  • Page 23 Goodrive300-16 special inverter for HVAC Commissioning guidelines 3.4.2 Commissioning steps of basic functions 1. Check the circuits and ensure proper wiring; 2. P00.18=1, restore to factory default; 3. Input the parameters of motor name plate to P2 group and do motor autotuning; 4.
  • Page 24 Goodrive300-16 special inverter for HVAC Commissioning guidelines Function Name Remark code value P06.05 Relay RO3 output Connect motor B variable frequency P06.06 Relay RO4 output Connect motor B power frequency P06.07 Relay RO5 output Connect motor C variable frequency P06.08 Relay RO6 output Connect motor C power frequency P06.09...
  • Page 25 Goodrive300-16 special inverter for HVAC Commissioning guidelines Function Name Remark code value the hold time is larger than P22.04. Hibernation starting Relative to the maximum PID1 value P22.03 5.0% deviation Allow hibernation only when the output feature is positive, feedback is larger than reference, the absolute value of the actual deviation is larger than the value and the hold time is larger than P22.04.
  • Page 26 Goodrive300-16 special inverter for HVAC Commissioning guidelines Function Name Remark code value actual deviation is larger than the value and the hold time is larger than P22.09. Hibernation waking P22.09 2.0s Min. hibernation time delay time Variable frequency P22.10 Circulation variable frequency motor motor operation P22.11 A motor type...
  • Page 27 Goodrive300-16 special inverter for HVAC Commissioning guidelines Function Name Remark code value Action of variable Adjustable according to the actual P22.27 frequency motor situations when reducing motor ACC time of variable Adjustable according to the actual P22.28 frequency motor 10.0s situations when reducing motor Multi-motor pressure...

  • Page 28: Commissioning Instruction Of Extension Functions

    Goodrive300-16 special inverter for HVAC Commissioning guidelines detection value may be decreasing, then set P22.29=1 to boost PID1 reference. 2. Generally, set P00.05 to non-zero and need to adjust the value according to the actual situations. In the ACC/DEC stage, when the inverter has no fault, suggest setting P00.11 and P00.12 to smaller values such as in 5s to ensure PID adjustment has quick response.
  • Page 29 Goodrive300-16 special inverter for HVAC Commissioning guidelines detection function of water level of intake sump for water supply applications. The inverter receives the signals of water level of intake sump in real time. If the water level changes from high to low, PID1 reference will be normal set value when the water level above lower limit; PID1 reference will be P22.43 when the water level below lower limit and above water shortage level;...

  • Page 30: Maintenance Intervals

    P18 group. The function facilitates analyzing and adjusting function parameters. 3.6 Maintenance intervals If installed in an appropriate environment, the inverter requires very little maintenance. The table lists the routine maintenance intervals recommended by INVT. Checking Item Method...
  • Page 31 Goodrive300-16 special inverter for HVAC Commissioning guidelines Checking Item Method Criterion does not mean that there is something wrong with the features. Ensure that there is no distortion or color-changing Visual examination of the conductors caused by lead overheating. of the Ensure that there are no conductors crackles or color-changing of...
  • Page 32 Goodrive300-16 special inverter for HVAC Commissioning guidelines Checking Item Method Criterion or measure with multimeters Transforme Hearing, smelling Ensure there is no abnormal and visual vibration, noise and smelling, examination reactors Ensure whether there is Electroma vibration noise in the Hearing gnetism contactors...

  • Page 33: Fault Instruction And Solution

    Do as the following after the inverter fault: 1. Check to ensure there is nothing wrong with the keypad. If not, please contact with the local INVT office. 2. If there is nothing wrong, please check P07 and ensure the corresponding recorded fault parameters to confirm the real state when the current fault occurs by all parameters.
  • Page 34 Goodrive300-16 special inverter for HVAC Commissioning guidelines Code Fault Cause Solution abnormal circuited) or the rotation is not The grounding is short smooth Check the output configuration. circuited or the output is Check if there is strong phase loss There is strong external interference interference Check the input power...
  • Page 35 Goodrive300-16 special inverter for HVAC Commissioning guidelines Code Fault Cause Solution U,V,W phase loss input(or Check the output distribution Output phase serious asymmetrical three Check the motor and cable loss phase of the load) Refer to the overcurrent solution Rectifying Redistribute dredge the wind Air duct jam or fan damage module...
  • Page 36 Goodrive300-16 special inverter for HVAC Commissioning guidelines Code Fault Cause Solution The offset between the reidentify Check the motor connection and parameters from autotune and the standard parameter set the parameter. Check if the upper limit is huge Autotune overtime frequency is above 2/3 of the rated frequency.
  • Page 37 Goodrive300-16 special inverter for HVAC Commissioning guidelines Code Fault Cause Solution Change the hardware and ask and affected by strong interference. for service. Communication fault. The connection of the Check the keypad wires and keypad wires is not good or broken.
  • Page 38 Goodrive300-16 special inverter for HVAC Commissioning guidelines Code Fault Cause Solution fault the synchronous motors not normal. Check whether the control set properly. The autotuning parameter is parameter is set properly or not. Increase the maladjustment not right. The inverter is not connected detection time.
  • Page 39 Goodrive300-16 special inverter for HVAC Commissioning guidelines Code Fault Cause Solution Corresponding resistor is not Draw out the correspond resistor communication Set the same baud rate fault dialed The communication baud Check the environment and rate is uneven avoid the interference. The ambient interference is too strong.

  • Page 40: Appendix A Function Parameters

    Goodrive300-16 special inverter for HVAC Appendix A Appendix A Function parameters For the convenience of function codes setting, the function group number corresponds to the first level menu, the function code corresponds to the second level menu and the function code parameter corresponds to the third level menu.
  • Page 41 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value 3:Reserved Note: 1, 2 and 3 are extension functions which need corresponding extension cards. Max. output ◎ P00.03 Max. (P00.04, 10.00)~400.00Hz 50.00Hz frequency Upper limit ◎...
  • Page 42 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value Keypad set ○ P00.10 0.00 Hz~P00.03 (Max. output frequency) 50.00Hz frequency Depend ○ P00.11 ACC time 1 0.0~3600.0s model Depend ○ P00.12 DEC time 1 0.0~3600.0s model Running 0: Runs at the default direction...
  • Page 43 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value Retention time of 0.0~50.0s ◎ P01.02 0.0s starting frequency The braking current ◎ P01.03 0.0~100.0% 0.0% before starting The braking ◎ P01.04 time before 0.00~50.00s 0.00s starting...
  • Page 44 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value between 1:Switch after the starting frequency FWD/REV rotation Stopping ◎ P01.15 0.00~100.00Hz 0.50Hz speed 0: Detect according to speed setting (no stopping Detection delay) ◎...
  • Page 45 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value power off Start delay ○ P01.23 0.0~60.0s 0.0s time Delay time ○ P01.24 of stop 0.0~100.0s 0.0s speed 0: Output without voltage 0Hz output 1: Output with voltage ○...
  • Page 46 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value asynchrono model us motor 1 Rotor Depend resistor of ○ P02.07 0.001~65.535Ω asynchrono model us motor 1 Leakage inductance Depend ○ P02.08 0.1~6553.5mH asynchrono model us motor 1...
  • Page 47 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value saturation coefficient 3 for the iron core of Magnetic saturation coefficient ◎ P02.14 0.0~100.0% 40.0% 4 for the iron core of 0: No protection Motor 1 1: Common motor (with low speed compensation).
  • Page 48 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value frequency Speed loop ○ P03.03 proportiona 0~200.0 20.0 l gain 2 Speed loop ○ P03.04 integral 0.000~10.000s 0.200s time 2 High ○ P03.05 switching P03.02~P00.03 (Max.
  • Page 49 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value setting 1: Keypad setting torque (P03.12) method 2: Analog AI1 setting torque 3: Analog AI2 setting torque 4: Analog AI3 setting torque 5: Pulse frequency HDI setting torque 6: Multi-step torque setting 7: MODBUS communication setting torque 8: Profibus/CANopen/BACnet/Devicenet...
  • Page 50 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value setting for upper frequency of forward rotation Keypad setting for upper ○ P03.17 0.00Hz~P00.03 50.00Hz frequency of reverse rotation Upper 0: Keypad setting upper-limit frequency electromoti 1: AI1 ○...
  • Page 51 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value coefficient in constant power zone Lowest weakening ○ P03.23 point in 10%~100% constant power zone Max. ◎ P03.24 0.0~120.0% 100.0% voltage limit Pre-excitin ○...
  • Page 52 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value of motor 1 ○ P04.03 frequency 1 0.00Hz~P04.05 0.00Hz of motor 1 ○ P04.04 voltage 1 of 0.0%~110.0% (the rated voltage of motor 1) 0.0% motor 1 ○...
  • Page 53 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value high frequency of motor 1 Vibration control ○ P04.12 0.00Hz~P00.03 (Max.output frequency) 30.00Hz threshold of motor 1 0: Straight line V/F curve 1: Multi-dots V/F curve Motor 2 V/F 2: 1.3 power low torque V/F curve...
  • Page 54 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value of motor 2 ○ P04.21 0.0%~110.0% (the rated voltage of motor 2) 0.0% voltage 3 of motor 2 V/F slip compensati ○ P04.22 0.0~200.0% 100.0% on gain of...
  • Page 55 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value 6: PID1 7: MODBUS communication 8: Profibus/CANopen/BACnet/Devicenet communication 9: Ethernet communication 10: Reserved Keypad ○ P04.28 setting 0.0%~100.0% 100.0% voltage Voltage ○ P04.29 increasing 0.0~3600.0s 5.0s...
  • Page 56 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value 4: Forward jogging terminals 5: Reverse jogging ◎ P05.02 function 6: Coast to stop selection 7: Fault reset 8: Operation pause 9: External fault input terminals ◎...
  • Page 57 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value 37: Shift the command to the terminals 38: Shift the command to the communication 39: Pre-magnetized command 40: Consumption power clear 41: Consumption power holding 42: Reserved 43: Reserved 44: PID1 integral pause...
  • Page 58 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value 71: Manual soft start of motor F 72: Manual soft start of motor G 73: Manual soft start of motor H 74: Upper limit of water level of inlet sump 75: Lower limit of water level of inlet sump 76: Water shortage level of inlet sump 77~79: Reserved...
  • Page 59 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value Switch-on ○ P05.16 delay of S2 0.000~50.000s 0.000s terminal Switch-off ○ P05.17 delay of S2 0.000~50.000s 0.000s terminal Switch-on ○ P05.18 delay of S3 0.000~50.000s 0.000s terminal...
  • Page 60 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value delay of S7 terminal Switch-off ○ P05.27 delay of S7 0.000~50.000s 0.000s terminal Switch-on ○ P05.28 delay of S8 0.000~50.000s 0.000s terminal Switch-off ○...
  • Page 61 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value limit of AI1 AI1 input ○ 0.000s~10.000s 0.100s P05.36 filter time Lower limit ○ P05.37 0.00V~P05.39 0.00V of AI2 Correspond ing setting ○ P05.38 -100.0%~100.0% 0.0%...
  • Page 62 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value Upper limit ○ P05.44~10.00V 10.00V P05.46 of AI3 Correspond ing setting ○ -100.0%~100.0% 100.0% P05.47 the upper limit of AI3 AI3 input ○ 0.000s~10.000s 0.100s P05.48...
  • Page 63 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value frequency ○ P05.54 0.000s~10.000s 0.010s input filter time P06 Group Output terminals 0: Open collector pole high speed pulse output ◎ P06.00 HDO output 1: Open collector pole output ○...
  • Page 64 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value 24: Profibus/CANopen/BACnet/Devicenet communication virtual terminals output 25: Ethernet communication virtual terminals output 26: Voltage establishment finished 27: Fire mode active state 28: Low PID1 feedback pre-alarm 29: High PID1 feedback pre-alarm 30: PID1 hibernation state 31: Realtime clock fault...
  • Page 65 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value Polarity of ○ 0~0x3FF 0~0x3FF P06.11 output terminals ○ 0.000~50.000s 0.000s P06.12 switch-on delay time ○ P06.13 switch-off 0.000~50.000s 0.000s delay time ○ P06.14 switch-on 0.000~50.000s...
  • Page 66 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value switch-off delay time ○ P06.22 switch-on 0.000~50.000s 0.000s delay time ○ P06.23 switch-off 0.000~50.000s 0.000s delay time ○ P06.24 0.000~50.000s 0.000s switch-on delay time ○...
  • Page 67 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value delay time ○ P06.32 AO1 output 0: Running frequency ○ 1: Set frequency P06.33 AO2 output 2: Ramp reference frequency 3: Running rotation speed 4: Output current (relative to the rated current of the inverter) 5: Output current (relative to the rated current of the...
  • Page 68 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value 27: PID1 feedback 28: PID2 reference 29: PID2 feedback 30: Reserved Lower ○ P06.35 -100.0%~P06.37 0.0% output limit of AO1 Correspond ing AO1 ○...
  • Page 69 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value correspondi ○ P06.43 ng AO2 0.00V~10.00V 10.00V output of upper limit AO2 output ○ P06.44 0.000s~10.000s 0.000s filter time Lower ○ P06.45 -100.0%~P06.47 0.00% output limit of HDO...
  • Page 70 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value 3: Download the keypad function parameter to local address (excluding the motor parameter of P02 and P12 group) 4: Download the keypad function parameters to local address (only for the motor parameter of P02 and P12 group) 0: No function...
  • Page 71 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value BIT5: running rotation speed (rpm on) BIT6: output power (% on) BIT7: output torque (% on) BIT8: PID1 reference (% flickering) BIT9: PID1 feedback value (% on) BIT10: input terminals state BIT11: output terminals state BIT12: torque set value (% on)
  • Page 72 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value BIT6: torque reference (% on) BIT7: AI1 (V on) BIT8: AI2 (V on) BIT9: AI3 (V on) BIT10: HDI frequency BIT11: PLC and the current stage in multi-step speed BIT12: pulse counters BIT13: reserved...
  • Page 73 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value High bit of 0~65535° (*1000) P07.15 power consumption Low bit of 0.0~999.9kWh P07.16 power consumption The rated ● P07.18 power of 0.4~3000.0kW the inverter The rated ●...
  • Page 74 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value 0: No fault 1: IGBT U phase protection(OUt1) 2: IGBT V phase protection(OUt2) 3: IGBT W phase protection(OUt3) 4: OC1 Current 5: OC2 ●...
  • Page 75 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value (E-CAN) 32: Grounding short circuit fault 1 (ETH1) 33: Grounding short circuit fault 2 (ETH2) 34: Speed deviation fault (dEu) 35: Maladjustment (STo) 36: Undervoltage fault (LL) 37: Clock chip fault (TI-E) Running...
  • Page 76 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value terminals state at current fault Output terminals ● P07.40 state at current fault Running frequency ● P07.41 0.00Hz at previous fault Ramp reference ●...
  • Page 77 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value Input terminals ● P07.47 state at previous fault Output terminals ● P07.48 state at previous fault Running frequency ● P07.49 0.00Hz at previous 2 fault Output voltage at...
  • Page 78 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value at previous 2 fault Input terminals ● P07.55 state at previous 2 fault Output terminals ● P07.56 state at previous 2 fault P08 Group Enhanced function Depend ○...
  • Page 79 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value Jogging ○ P08.06 0.00Hz~P00.03 (Max.output frequency) 5.00Hz frequency Depend Jogging ○ P08.07 0.0~3600.0s ACC time model Depend Jogging ○ P08.08 0.0~3600.0s DEC time model Jumping ○...
  • Page 80 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value Traverse ○ 0.1~3600.0s P08.18 declining 5.0s time Setting ○ P08.25 counting P08.26~65535 value Reference ○ P08.26 counting 0~P08.25 value Set running ○ P08.27 0~65535min 0min time...
  • Page 81 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value 1: Enabled FDT1 electrical ○ P08.32 level 0.00Hz~P00.03 (Max.output frequency) 50.00Hz detection value FDT1 retention ○ P08.33 -100.0~100.0% (FDT1 electrical level) 5.0% detection value FDT2 electrical...
  • Page 82 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value running 1:The fan keeps running after power on mode 0x00~0x21 LED ones: PWM mode selection 0: PWM mode 1, three-phase modulation and two-modulation ◎...
  • Page 83 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value 0: Setting is valid 1: Valid during running, cleared after stopping 2: Valid during running, cleared after receiving the stop command LED thousands: ∧/∨ keys and digital potentiometer integral function 0: The integral function is valid 1: The integral function is invalid...
  • Page 84 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value frequency changing ratio 0x000~0x111 LED ones: Action selection when power off. 0: Save when power off 1: Clear when power off LED tens: Action selection when MODBUS set Frequency frequency off ○...
  • Page 85 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value 4: V 5: % 6: m/s 7: m/Min 8: m/h 9: m3/s 10: m3/Min 11: m3/h 12: Kg/s 13: Kg/Min 14: Kg/h 15~21: Reserved Displayed ◎...
  • Page 86 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value 10: Reserved 0: P09.07 1: P09.08 2: AI1 3: AI2 4: AI3 PID1 ○ 5: HDI P09.06 reference 6: Multi-step speed source 2 7: MODBUS 8: Profibus-DP/CANopen/BACnet 9: Ethernet...
  • Page 87 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value 4: MODBUS 5: Profibus-DP/CANopen/BACnet 6: Ethernet 7: Reserved PID1 ○ P09.12 feedback 0.000~60.000s 0.000s filter time Feedback source 1 ○ P09.13 0.00~600.00 1.00 conversion gain Feedback...
  • Page 88 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value minimum positive deviation as PID reference and feedback. 7: Multi-reference maximum positive deviation and minimum negative deviation Calculate the difference of reference source 1 and feedback source 1, reference source 2 and feedback source 2 and consider the case when the feedback is smaller than the reference in priority.
  • Page 89 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value lower limit 0x000~0x111 LED ones: Integral anti-saturation 0: Keep on integral adjustment when the frequency achieves the upper and low limit; the integration shows the change between the reference and the feedback unless it reaches the internal integral limit.
  • Page 90 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value separation threshold Differential ○ P09.28 0~30 filter times PID1 output ○ P09.29 0.30~3.00 1.00 gain PID1 output ○ P09.30 0.000~60.000s 0.000s filter time Feedback -100.0~100.0% upper limit...
  • Page 91 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value time of step Multi-step ○ P10.04 -100.0~100.0% 0.0% speed 1 Running ○ P10.05 time of step 0.0~6553.5s(m) 0.0s Multi-step ○ P10.06 -100.0~100.0% 0.0% speed 2 Running ○...
  • Page 92 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value Multi-step ○ P10.16 -100.0~100.0% 0.0% speed 7 Running ○ P10.17 time of step 0.0~6553.5s(m) 0.0s Multi-step ○ -100.0~100.0% 0.0% P10.18 speed 8 Running ○...
  • Page 93 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value Multi-step ○ -100.0~100.0% 0.0% P10.28 speed 13 Running ○ P10.29 time of step 0.0~6553.5s(m) 0.0s Multi-step ○ -100.0~100.0% 0.0% P10.30 speed 14 Running ○...
  • Page 94 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value 0: Output phase loss protection disable 1: Output phase loss protection enable LED hundreds: 0: Hardware input phase loss protection disable 1: Hardware input phase loss protection enable Frequency- decreasing 0: Disable...
  • Page 95 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value Automatic ◎ P11.06 50.0~200.0% 160.0% current limit Frequency- decreasing 3.00 ◎ P11.07 0.00~50.00Hz/s ratio during Hz/s current limit 0x000~0x131 LED ones: 0: Overload pre-alarm of the motor, relative to the rated current of the motor 1: Overload pre-alarm of the inverter, relative to the rated current of the inverter...
  • Page 96 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value Overload ○ P11.11~200% 150% P11.09 pre-alarm detection Overload pre-alarm ○ 0.01~360.00s 1.00s P11.10 detection time Underload ○ P11.11 pre-alarm 0%~ P11.09 detection Underload pre-alarm ○...
  • Page 97 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value at voltage drop P12 Group Motor 2 Rated Depend power of ◎ P12.01 0.1~3000.0kW asynchrono model us motor 2 Rated frequency ◎ P12.02 0.01Hz~P00.03 (Max.output frequency) 50.00Hz asynchrono...
  • Page 98 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value us motor 2 Leakage inductance Depend ○ P12.08 0.1~6553.5mH asynchrono model us motor 2 Mutual inductance Depend ○ P12.09 0.1~6553.5mH asynchrono model us motor 2 Non-load Depend current of...
  • Page 99 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value iron core of Magnetic saturation coefficient ◎ P12.14 0.0~100.0% 40.0% 4 for the iron core of 0: No protection Motor 2 1: Common motor (with low speed compensation) ◎...
  • Page 100 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value 7: 115200BPS 0: No check (N,8,1) for RTU 1: Odd check (E,8,1) for RTU Digital bit 2: Even check (O,8,1) for RTU ○ P14.02 checkout 3: No check (N,8,2) for RTU...
  • Page 101 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value Module ◎ P15.01 0~127 address PZD2 0: Invalid ○ P15.02 receiving 1: Setting frequency (0~Fmax(unit:0.01Hz)) 2: PID1 reference source 1, range(0~1000,1000 PZD3 ○ P15.03 corresponds to 100.0%) receiving...
  • Page 102 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value 14: Bacnet read input function parameter 15: Bacnet write input function parameter 16: Bacnet write input function code 17: PID1 reference source 2, range(0~1000,1000 corresponds to 100.0%) 18: PID1 feedback source 2, range(0~1000,1000 corresponds to 100.0%)
  • Page 103 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value sending 21: Control word 22: Bacnet read function return value 23: PID1 output 24: PID2 reference 25: PID2 feedback 26: PID2 output 27~29: Reserved Temporarily ○...
  • Page 104 73: ODVA extension speed and torque control P15.32 ○ input input instance 74: INVT basic speed control input 75: INVT extension speed control input 76: INVT speed and torque control input 77: INVT extension speed and torque control input Status P15.33 ○ changing/C ycle...
  • Page 105 ○ enabling input input 74: INVT basic speed control input instance 75: INVT extension speed control input 76: INVT speed and torque control input 77: INVT extension speed and torque control input Component P15.36 ○ 19 output 8~32 length Component P15.37...
  • Page 106 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value variable P16 Group Ethernet function Speed 0: Self-adapting setting of 1: 100M full duplex ◎ P16.00 2: 100M semiduplex Ethernet 3: 10M full duplex communica 4: 10M semiduplex tion...
  • Page 107 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value Ramp ● P17.02 reference 0.00Hz~P00.03 0.00Hz frequency Output ● P17.03 0~1200V voltage Output ● P17.04 0.0~3000.0A 0.0A current Motor ● P17.05 0~65535RPM 0RPM speed Torque ●...
  • Page 108 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value Torque ● P17.15 -300.0%~300.0% (the rated current of the motor) 0.0% reference Linear ● P17.16 0~65535 speed Counting ● P17.18 0~65535 value AI1 input ●...

  • Page 109: A.2 Goodrive300-16 Special Function Parameters

    Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value controller output Magnetic ● P17.32 0.0%~200.0% 0.0% flux linkage Exciting ● P17.33 current -3000.0~3000.0A 0.0A reference Torque ● P17.34 current -3000.0~3000.0A 0.0A reference ●...
  • Page 110 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value HVAC 0: Invalid ● P18.00 function 1: Valid status SN of running 1~8 corresponds to motor A~F, 0 stands for no ● P18.01 variable valid variable frequency motor and 255 stands for frequency...
  • Page 111 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value time of variable frequency motors to be circulated 0: Stop 1: Normal running ● P18.08 PID1 status 2: Dead area 3: Hibernation Current PID1 ●...
  • Page 112 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value Current ● P18.17 PID2 -100.0~100.0% 0.0% reference PID2 ● P18.18 -100.0~100.0% 0.0% feedback PID2 bias ● P18.19 -100.0~100.0% 0.0% input PID2 proportional ● P18.20 -1000.0~1000.0% 0.0%...
  • Page 113 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value 11: m3/h 12: Kg/s 13: Kg/Min 14: Kg/h 15~21: Reserved Displayed ◎ P19.01 decimal places 0.001~65.535 Max. PID2 ○ P19.02 3 decimal places, the decimal place changes along 1.000 reference with P19.01...
  • Page 114 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value 0: AI1 1: AI2 2: AI3 PID2 3: HDI ○ feedback P19.08 4: MODBUS source 5: Profibus-DP/CANopen/BACnet/Devicenet 6: Ethernet 7: Reserved PID2 ○ feedback 0.000~60.000s 0.000s...
  • Page 115 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value Integral ○ P19.20 separation 0.0~200.0% 200.0% threshold Differential ○ P19.21 0~60 filter times PID2 output ○ P19.22 0.30~3.00 1.00 gain PID2 output ○ P19.23 0.000~60.000s 0.000s...
  • Page 116 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value P20 Group Realtime clock and timing function ○ P20.00 Set year 0000~9999YY 2014YY Set month 01.01M ○ P20.01 01.01~12.31MMDD and day ○ P20.02 Set week 1~7, corresponding to Monday to Sunday 00.00~23.59HHMM...
  • Page 117 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value when inverter stops Second when ○ P20.08 00~59s inverter stops 0: Disabled ○ P20.09 Clock fault 1: Enabled Current ● P20.10 00~59s second P21 Group Fire override function 0: Invalid...
  • Page 118 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value month and day when fire enabled Current time ● 00.00~23.59 00.00 P21.04 when fire enabled P22 Group HVAC special function HVAC 0: Invalid ◎...
  • Page 119 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value time Used to avoid the case where the inverter runs continuously when the running frequency reaches the upper limit while the feedback cannot reach the set value after boost, the inverter will enter hibernation immediately after boost time.
  • Page 120 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value type 1: Variable frequency motor selection 2: Power frequency motor B motor 0: Invalid ◎ P22.12 type 1: Variable frequency motor selection 2: Power frequency motor C motor 0: Invalid ◎...
  • Page 121 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value Delay time when ○ P22.21 0.0~3600.0s 10.0s adding motor Switch frequency when adding ○ P22.22 P00.05~P00.03 50.00Hz variable frequency motor DEC time of variable frequency motor when...
  • Page 122 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value Action of variable 0: Frequency does not change frequency ○ P22.27 1: Accelerate to the running frequency when motor when adding motor reducing motor ACC time of variable...
  • Page 123 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value Circulation 0.0~6000.0h cycle of Automatic circulation among idle power frequency ○ P22.33 0.0h power motors, no circulation in the stage of adding or reducing motors or hibernation, no circulation all frequency the time when setting to 0...
  • Page 124 Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value 4: AI3 5: MODBUS communication 6: Profibus/CANopen/BACnet/Devicenet communication Upper limit of water ○ P22.40 0.0~100.0% 60.0% level of inlet sump Lower limit of water ○...

  • Page 125: A.3 Goodrive300-16 Communication Additions

    Goodrive300-16 special inverter for HVAC Appendix A Function Default Name Detailed instruction of parameters Modify code value than P22.47. Emergency stop ○ P22.48 0.0~600.0s 2.0s deceleration time A.3 Goodrive300-16 communication additions 1. MODBUS communication Function Address Data meaning instruction instruction definition characteristics Communication...
  • Page 126 Goodrive300-16 special inverter for HVAC Appendix A Function Address Data meaning instruction instruction definition characteristics corresponds to 100.0%) PID2 feedback, range (0~1000, 1000 2012H corresponds to 100.0%) Water level of inlet sump, range (0~1000, 2013H 1000 corresponds to 100.0%) Bit7: fire enabled state Bit8: low PID1 feedback pre-alarm Bit9: high PID1 feedback pre-alarm SW 2 of the...

  • Page 127: Appendix B Dimension Drawings

    Goodrive300-16 special inverter for HVAC Appendix B Appendix B Dimension drawings B.1 Keypad structure and dimension B.1.1 Keypad structure Note: The LED keypad is standard and the LCD keypad which can support various languages, parameters copy and 10-line displaying is optional. B.1.2 Keypad dimension Installation dimension without bracket...

  • Page 128: B.2 Dimensions For Wall Installation

    Goodrive300-16 special inverter for HVAC Appendix B B.1.3 Installation bracket (optional) 28.4 4-M4x15(riveting screw) 137.5 4-M4x15(riveting screw) 4-R13 Installation bracket Installation dimension Note: It is necessary to use M3 screw or installation bracket to fix the external keypad. The installation bracket for inverters of 380V 1.5~30kW and 500V 4~18.5kW is optional but it is standard for the inverters of 380V 37~500kW, 500V 22~500kW and 660V.

  • Page 129: B.3 Dimensions For Flange Installation

    Goodrive300-16 special inverter for HVAC Appendix B Wall installation of 380V 132kW inverters Installation dimension (unit:mm) Installation Model hole 4kW~5.5kW 243.5 7.5kW~15kW 331.5 303.5 18.5kW 22kW~30kW 37kW~55kW 75kW~110kW 132kW B.3 Dimensions for flange installation Flange installation of 380V 4-30kW inverters...
  • Page 130 Goodrive300-16 special inverter for HVAC Appendix B Flange installation of 380V 37-110kW inverters Flange installation of 380V 132kW inverters Installation dimension (unit:mm) Installation Model hole 4kW~5.5kW 79.5 7.5kW~15kW 174 11.5 370 216.2 18.5kW 22kW~30kW 37kW~55kW 261 65.5 555 75kW~110kW 317 58.5 680 132kW 358 178.5...

  • Page 131: Appendix C Peripherial Options And Parts

    Goodrive300-16 special inverter for HVAC Appendix C Appendix C Peripherial options and parts Parts Model Remark Chinese/English LCD keypad PRD_LCD300-16_ZY Relay extension board EC-RL-106 6 NO outputs PROFIBUS+Ethernet EC-TX-103 communication card CANopen communication card EC-TX-105 Devicenet communication card EC-TX-106 BACnet card EC-TX-107 C.1 Breaker and electromagnetic contactor (optional) It is necessary to add fuse for the avoidance of overload.

  • Page 132: C.2 Reactors (Optional)

    If the distance between the inverter and motor is 50~100m, see the table below for model selection; if it exceeds 100m, consult with INVT technical support. The inverters of 380V (≥37kW), 500V (≥22kW) and of 660V are equipped with external DC reactors for the improvement of power factors and the avoidance of damage from high input current to the rectifying components because of the high-capacity transformer.

  • Page 133: C.3 Filter (Optional)

    Goodrive300-16 special inverter for HVAC Appendix C C.2.1 Reactor selection Model Input reactor DC reactor Output reactor GD300-16-004G/5R5P-4 ACL2-004-4 OCL2-004-4 GD300-16-5R5G/7R5P-4 ACL2-5R5-4 OCL2-5R5-4 GD300-16-7R5G/011P-4 ACL2-7R5-4 OCL2-7R5-4 GD300-16-011G/015P-4 ACL2-011-4 OCL2-011-4 GD300-16-015G/018P-4 ACL2-015-4 OCL2-015-4 GD300-16-018G/022P-4 ACL2-018-4 OCL2-018-4 GD300-16-022G/030P-4 ACL2-022-4 OCL2-022-4 GD300-16-030G/037P-4 ACL2-030-4 OCL2-030-4 GD300-16-037G/045P-4 ACL2-037-4...
  • Page 134 Goodrive300-16 special inverter for HVAC Appendix C The input interference filter can decrease the interference of the inverter to the surrounding equipments. Output interference filter can decrease the radio noise cause by the cables between the inverter and the motor and the leakage current of the conducting wires. Our company configured some filters for the convenience of the users.
  • Page 135 Goodrive300-16 special inverter for HVAC Appendix C GD300-16-7R5G/011P-4 FLT-P04032L-B FLT-L04032L-B GD300-16-011G/015P-4 GD300-16-015G/018P-4 FLT-P04045L-B FLT-L04045L-B GD300-16-018G/022P-4 GD300-16-022G/030P-4 FLT-P04065L-B FLT-L04065L-B GD300-16-030G/037P-4 GD300-16-037G/045P-4 FLT-P04100L-B FLT-L04100L-B GD300-16-045G/055P-4 GD300-16-055G/075P-4 FLT-P04150L-B FLT-L04150L-B GD300-16-075G/090P-4 GD300-16-090G/110P-4 GD300-16-110G/132P-4 FLT-P04240L-B FLT-L04240L-B GD300-16-132G/160P-4 Note: 1. The input EMI meet the requirement of C2 after installing input filters. 2.
