Goodrive350-19 series VFD for crane
Function
code
P06.14
P06.17 AO1 output lower limit
P06.18 corresponding to lower
P06.19 AO1 output upper limit
P06.20 corresponding to upper
P06.21 AO1 output filter time
Slave parameters:
Function
code
Setting channel of A
P00.06
frequency command
P05.24 AI1 lower limit
Corresponding setting
P05.25
of AI1 lower limit
P05.26 AI1 upper limit
Corresponding setting
P05.27
of AI1 upper limit
P05.28 AI1 input filter time
Frequency decrease
P08.30
ratio in drop control
2. Analog terminal master/slave mode b
The master adopts the speed control mode and sends the torque current to the slave AI1 terminal
through the AO1 terminal. The slave adopts the torque control mode and the torque reference is set
by the AI1 terminal.
Master parameters:
Function
code
P06.14
P06.17 AO1 output lower limit Setting range of P06.17:
P06.18
Name
AO1 output 2: Ramp reference frequency
AO1 output
Setting range of P06.17:
limit
P06.18
P06.19
P06.20
AO1 output
P06.21
limit
Name
1: AI1
P05.24
P05.25
P05.26
P05.27
P05.28
0.00–50.00Hz
Name
22: Torque current (relative to triple the motor
AO1 output
rated current)
AO1 output P06.18
Description
-300.0%–P06.19
setting range: 0.00V–10.00V
setting range: P06.17–100.0%
setting range: 0.00V–10.00V
setting range: 0.000s–10.000s
Description
setting range: 0.00V–P05.26
setting range: -300.0% –300.0%
setting range: P05.24–10.00V
setting range: -300.0% –300.0%
setting range: 0.000s–10.000s
Description
-300.0%–P06.19
setting range: 0.00V–10.00V
-99-
Commissioning guidelines
Setting
2
0.0%
0.00V
100.0%
10.00V
0.000s
Setting
1
0.00V
0.0%
10.00V
100.0%
0.030s
1.00hz
Setting
22
0.0%
0.00V
