Goodrive350-19 series VFD for crane
Function
Name
code
P13.03 Pull-in current 2
Source-current
P13.04 switchover
frequency
P13.05 Reserved
High-frequency
P13.06 superposition
voltage
P13.07 Reserved
Control parameter
P13.08
1
Control parameter
P13.09
2
P13.10 Reserved
Maladjustment
P13.11
detection time
Description
Setting range: 0.0%–100.0% (of the motor
rated current)
Pull-in current is the pole position orientation
current; pull-in current 2 is valid within the lower
limit of pull-in current switch-over frequency
threshold. You do not need to change the value
in most cases.
Setting range: 0.0%–100.0% (of the motor rated
current)
0.00Hz–P00.03(Max. output frequency)
200Hz–1000Hz
Used to set the pulse current threshold when the
initial magnetic pole position is detected in the
pulse mode, The value is a percentage in
relative to the rated current of the motor.
Setting range: 0.0–300.0% (of the motor rated
voltage)
0.0–400.0
0–0xFFFF
Used to set the frequency threshold for enabling
the counter-electromotive force phase-locked
loop in SVC 0. When the running frequency is
lower than the value of the function code, the
phase-locked loop is disabled; and when the
running frequency is higher than that, the
phase-locked loop is enabled.
Setting range: 0–655.35
0.0–359.9
Used to adjust the responsiveness of
anti-maladjustment function. If the load inertia is
large, increase the value of this parameter
properly, however, the responsiveness may
slow down accordingly.
Setting range: 0.0–10.0s
-283-
Function parameter list
Default Modify
○
10.0%
○
10.00Hz
◎
500Hz
◎
100.0%
○
0.0
○
0
○
2.00
○
0.0
○
0.5s
