Goodrive350-19 series VFD for crane
Function
Name
code
P17.16 Linear speed
P17.17 Reserved
P17.18 Count value
P17.19 AI1 input voltage
P17.20 AI2 input voltage
HDIA input
P17.21
frequency
HDIB input
P17.22
frequency
PID reference
P17.23
value
PID feedback
P17.24
value
Motor power
P17.25
factor
Duration of this
P17.26
run
Simple PLC and
P17.27 actual step of
multi-step speed
Motor ASR
P17.28
controller output
Pole angle of
P17.29
open-loop SM
Phase
P17.30 compensation of
SM
High-frequency
P17.31 superposition
current of SM
P17.32 Motor flux linkage 0.0%–200.0%
P17.33 Exciting current Displays the exciting current reference value
Description
0–65535
0–65535
0–65535
Displays the AI1 input signal.
Range: 0.00–10.00V
Displays the AI2 input signal.
Range: -10.00V–10.00V
Display HDIA input frequency.
Range: 0.000–50.000kHz
Display HDIB input frequency.
Range: 0.000–50.000kHz
Displays the PID reference value.
Range: -100.0–100.0%
Displays the PID feedback value.
Range: -100.0–100.0%
Displays the power factor of the current motor.
Range: -1.00–1.00
Displays the duration of this run of the VFD.
Range: 0–65535min
Displays simple PLC and present step number
of multi-step speed.
Range: 0–15
Displays the ASR controller output value under
the vector control mode, relative to the
percentage of rated motor torque.
Range: -300.0%–300.0% (of the motor rated
current)
Displays the initial identification angle of SM.
Range: 0.0–360.0
Displays the phase compensation of SM.
Range: -180.0–180.0
0.0%–200.0% (of the motor rated current)
-289-
Function parameter list
Default Modify
●
0
●
0
●
0
●
0.00V
●
0.00V
0.000
●
kHz
●
0.000 kHz
●
0.0%
●
0.0%
●
1.00
●
0m
●
0
●
0.0%
●
0.0
●
0.0
●
0.0
●
0.0%
●
0.0A
