Goodrive350-19 series VFD for crane
Fault
Fault type
code
Communication
timeout of
C3-Er
expansion card at
card slot 3
PROFIBUS card
E-DP communication
timeout fault
Ethernet card
E-NET communication
timeout fault
CANopen card
E-CAN communication
timeout fault
PROFINET card
E-PN communication
timeout fault
EtherCAT card
E-CAT communication
timeout fault
BACNet card
E-BAC communication
timeout fault
DeviceNet card
E-DEV communication
timeout fault
Possible cause
There is no data transmission in
interface at card slot 3.
There is no data transmission
between the communication
card and the upper computer
(or PLC).
There is no data transmission
between the communication
card and the upper computer.
There is no data transmission
between the communication
card and the upper computer
(or PLC).
There is no data transmission
between the communication
card and the upper computer
(or PLC).
There is no data transmission
between the communication
card and the upper computer
(or PLC).
There is no data transmission
between the communication
card and the upper computer
(or PLC).
There is no data transmission
between the communication
card and the upper computer
(or PLC).
-382-
Troubleshooting
Solution
insertion port after power-off.
Confirm whether the expansion
card inserted can be supported;
Stabilize the expansion card
interfaces after power-off, and
check whether the fault persists at
next power-on.
Check whether the insertion port
is damaged. If yes, replace the
insertion port after power-off.
Check whether the
communication card wiring is
loose or dropped.
Check whether the
communication card wiring is
loose or dropped.
Check whether the
communication card wiring is
loose or dropped.
Check whether the
communication card wiring is
loose or dropped.
Check whether the
communication card wiring is
loose or dropped.
Check whether the
communication card wiring is
loose or dropped.
Check whether the
communication card wiring is
loose or dropped.
