INVT Goodrive350-19 Series Operation Manual page 154

Goodrive350-19 series VFD for crane
Function
Name
code
Setting source
of reverse
rotation
P03.15
upper-limit
frequency in
torque control
Forward rotation
upper-limit
P03.16 frequency set
through keypad
in torque control
Reverse rotation
upper-limit
P03.17 frequency set
through keypad
in torque control
Setting source
of electromotive
P03.18
torque upper
limit
Setting source
of braking
P03.19
torque upper
limit
P03.20 Electromotive 0.0–300.0% (of the motor rated current)
the max. frequency.
0: Keypad (P03.17)
1–11: Same as those for P03.14
Setting range: 0.00 Hz–P00.03 (Max. output frequency)
0: Keypad (P03.20)
1: AI1 (100% corresponding to triple the motor rated
current)
2: AI2
3: AI3
4: Pulse frequency HDIA
5: Modbus communication
6: PROFIBUS/CANopen/DeviceNet communication
7: Ethernet communication
8: Pulse frequency HDIB (100% corresponding to triple
the motor rated current)
9: EtherCAT/Profinet communication
10: Programmable expansion card
11: 216 communication
Note: For setting sources 1–4 and 8, 100%
corresponds to three times the rated motor current.
0: Keypad (P03.21)
1–10: Same as those for P03.18
-142-
Description
Basic operation guidelines
Default
0
50.00Hz
50.00Hz
0
0
250.0%
