Goodrive300-19 series open loop vector inverter special for hosit
Polarity of
P06.05 output
terminals
Y switch-on
P06.06
delay time
Y switch-off
P06.07
delay time
HDO switch-on
P06.08
delay time
HDO switch-off
P06.09
delay time
RO1 switch-on
P06.10
delay time
RO1 switch-off
P06.11
delay time
RO2 switch-on
P06.12
delay time
RO2 switch-off
P06.13
delay time
Max.
P07.38 temperature at
current fault
Digital output
P17.13
terminals state

7.13 Multi-step speed running

Set the parameters when the inverter carries out multi-step speed running. Goodrive300-19 series
inverters can set 16 stages speed which can be selected by the combination code of multi-step speed
terminals 1~4. They correspond to multi-step speed 0 to 15.
36: Ready for switching on
37: Motor 2 in operation
38~40: Reserved
00~0F
0.000~50.000s
0.000~50.000s
0.000~50.000s (only valid when P06.00=1)
0.000~50.000s (only valid when P06.00=1)
0.000~50.000s
0.000~50.000s
0.000~50.000s
0.000~50.000s
-172-
Basic operation instruction
00
0.000s
0.000s
0.000s
0.000s
0.000s
0.000s
0.000s
0.000s
0.0° C
0
