Goodrive350-19 series VFD for crane
Note: Turn SW2 on the control board to "I" for current output.
Procedure
1. Connect PT100/PT1000 according to the figure.
2. Set P92.22=1 to select PT100, or set P92.22=2 to select PT1000.
3. Set P92.23 (AI detected motor overtemperature protection threshold) and P92.24 (AIdetected
motor overtemperature alarm threshold).
4. Check whether P94.20 (AI detected motor temperature) is correct.
Function parameter settings
Function
Name
code
Type of sensor for
P92.22 AI to detect motor
temperature
AI detected motor
P92.23 overtemperature
protection threshold
AI detected motor
P92.24 overtemperature
pre-alarm threshold
P92.21 overtemperature
selection
AI detected motor
P94.20
temperature
1: PT100
2: PT1000
0.0–200.0° C
0.0–200.0° C
0: The PTC function is enabled through terminal
selection. When the PTC overtemperature alarm
PTC A-Ptc is reported, this cannot terminate normal
running.
1: The PTC function is valid through terminal
selection. When the PTC overtemperature fault PtcE
is reported, this results in stop.
-20.0–200.0° C
Description
-127-
Commissioning guidelines
Setting
1 or 2
110.0
90.0
0
0.0° C
