7 Frequency level detection FDT2 (Refer to the descriptions for P08.34–P08.35.)
8 Frequency reached
9 Running in zero speed
10 Upper limit frequency reached
11 Lower limit frequency reached
12 Ready for running
13
14 Overload pre-alarm
15 Underload pre-alarm
16 Simple PLC stage completed
17 Simple PLC cycle completed
18 Set counting value reached
Designated counting value
19
20 External fault is valid
22 Running time reached
Modbus communication
23
virtual terminal output
PROFIBUS/CANopen/DeviceNet
24 communication virtual terminal
Function
Pre-exciting
reached
output
Description
(Refer to the description for P08.36.)
The ON signal is output when the VFD output
frequency and reference frequency are both zero.
The ON signal is output when the running frequency
reaches upper limit frequency.
The ON signal is output when the running frequency
reached lower limit frequency.
Main circuit and control circuit powers are
established, the protection functions do not act;
when the VFD is ready to run, output ON signal.
The ON signal is output during pre-exciting of the
VFD.
The ON signal is output when the pre-alarm time
elapsed based on the pre-alarm threshold; see
P11.08–P11.10 for details.
The ON signal is output when the pre-alarm time
elapsed based on the pre-alarm threshold. For
details, see the descriptions for P11.11–P11.12.
When the present state of the simple PLC is
completed, it outputs a signal.
When a single cycle of the simple PLC is completed,
it outputs a signal.
The ON signal is output when the set counting value
is reached.
The ON signal is output when the designated
counting value is reached.
The ON signal is output when an external fault is
valid.
The ON signal is output when the running time is
reached.
A signal is output based on the value set through
Modbus communication. When the value is 1, the
ON signal is output; when the value is 0, the OFF
signal is output.
A signal is output based on the value set through
PROFIBUS/CANopen/DeviceNet communication.
When the value is 1, the ON signal is output; when
