Function parameter settings
Function
Name
code
Enabling
PT100/PT1000
P92.12
temperature
detection
Enabling
PT100/PT1000
P92.13
disconnection
detection
PT100
P92.14 overtemperature
protection point
PT100
P92.15 overtemperature
pre-alarm point
PT100 present
P94.16
temperature
PT100 present
P94.17
digital
PT1000 present
P94.18
temperature
PT1000 present
P94.19
digital
(2) Through an AI terminal
Figure 5-26 Wiring between analog terminals and PT100/PT1000
Description
Ones place: whether to enable PT100 temperature
detection
0: Disable
1: Enable
Tens place: whether to enable PT1000 temperature
detection
0: Disable
1: Enable
Ones place: whether to enable PT100 disconnection
detection
0: Disable
1: Enable
0.0–150.0° C
0.0–150.0° C
-50.0–150.0° C
0–4096
-50.0–150.0° C
0–4096
-126-
Commissioning guidelines
Setting
0x01 or
0x10
0x01
120.0° C
100.0° C
0.0° C
0
0.0° C
0
