Function
Name
code
temperature
upper limit
PT100/PT1000
calibrated
P92.19
temperature lower
limit
Digital of
PT100/PT1000
P92.20
calibrated
temperature
PTC
P92.21 overtemperature
selection
Type of sensor for
P92.22 AI to detect motor
temperature
AI detected motor
overtemperature
P92.23
protection
threshold
AI detected motor
P92.24 overtemperature
pre-alarm
Description
-20.0–50.0° C
0–4
0: Normal detection
1: PT100 lower limit digital calibration autotuning
2: PT100 upper limit digital calibration
autotuning
3: PT1000 lower limit digital calibration
autotuning
4: PT1000 upper limit digital calibration
autotuning
After autotuning is completed, the function code
is automatically cleared, and the cablibration
value is automatically saved to the I/O card.
0–1
0: The PTC function is enabled through terminal
selection. When the PTC overtemperature alarm
A-Ptc is reported, this cannot terminate normal
running.
1: The PTC function is enabled through terminal
selection. When the PTC overtemperature fault
PtcE is reported, this results in stop.
0–3
0: None
1: PT100
2: PT1000
3: KTY84
0.0–200.0° C
0.0–200.0° C
-357-
Function parameter list
Default Modify
○
20.0° C
○
0
◎
0
○
0
○
110.0
○
90.0
