Goodrive350-19 series VFD for crane
Setting Function
Decrease frequency
11
setting (DOWN)
Clear the frequency
12
increase/decrease setting
Switch between A setting
13
and B setting
Switch between
14 combination setting and A
Switch between
15 combination setting and B
16 Multi-step speed terminal 1 A total of 16-step speeds can be set by combining digital
17 Multi-step speed terminal 2
18 Multi-step speed terminal 3
19 Multi-step speed terminal 4
Pause multi-step speed
20
21 ACC/DEC time selection 1 The status of the two terminals can be combined to select
22 ACC/DEC time selection 2
(UP) when the frequency is given by external terminals.
The terminal used to clear frequency-increase/decrease
setting can clear the frequency value of auxiliary channel
set by UP/DOWN, thus restoring the reference frequency to
the frequency given by main reference frequency command
channel.
Used to switch between the frequency setting channels.
A frequency reference channel and B frequency reference
channel can be switched by function 13; the combination
channel set by P00.09 and the A frequency reference
setting
channel can be switched by function 14; the combination
channel set by P00.09 and the B frequency reference
channel can be switched by function 15.
setting
states of these four terminals.
Note: Multi-step speed 1 is the low-order bit, and multi-step
speed 4 is the high-order bit.
The multi-step speed selection function can be screened to
running keep the set value in the present state.
four groups of ACC/DEC time.
K1
UP terminal
K2
DOWN terminal
UP/DOWM
K3
Zeroing terminal
COM
Multi-step Multi-step
speed 4 speed 3
BIT3 BIT2
Terminal Terminal
1 2
OFF OFF
ON OFF
OFF ON
ON ON
-177-
Basic operation guidelines
Description
Multi-step
speed 2
BIT1
ACC/DEC time
ACC/DEC time 1 P00.11/P00.12
ACC/DEC time 2 P08.00/P08.01
ACC/DEC time 3 P08.02/P08.03
ACC/DEC time 4 P08.04/P08.05
Multi-step
speed 1
BIT0
Parameter
