5.11.4 Commissioning parameters

Function
code
P90.04 Enabling brake-oriented logic
Enabling forward torque for
P90.05
reverse-running start/stop
P90.12 Forward brake release current
P90.13 Reverse brake release current
P90.14 Forward brake release torque
P90.15 Reverse brake release torque
Forward brake release
P90.16
P90.17 Reverse brake release
Name
frequency
Description
0–1
0: The brake is controlled by an
external controller.
1: The brake is controlled by the
VFD.
0x00–0x11
Ones place: indicates whether to
enable forward torque for
reverse-running start
0: Disable
(The reverse-running start direction
complies with the command.)
1: Enable
(The reverse-running start direction is
always the forward-running
direction.)
Tens place: indicates whether to
enable forward torque for
reverse-running stop
0: Disable
(The reverse-running stop direction
complies with the command.)
1: Enable
(The reverse-running stop direction is
always the forward-running
direction.)
0.0–200.0% (of the motor rated
current)
0.0–200.0% (of the motor rated
current)
0.0–200.0% (of the motor rated
torque)
0.0–200.0% (of the motor rated
torque)
0.00–20.00Hz
0.00–20.00Hz
-79-
Commissioning guidelines
Default
0
0x00
0.0%
0.0%
0.0%
0.0%
3.00Hz
3.00Hz
