Goodrive350-19 series VFD for crane
motors and the leakage current of conducting wires.
INVT provides some of the filters for you to choose.
D.8.1 Filter model description
Field
A FLT: VFD filter series
Filter type
B P: Power input filter
L: Output filter
Voltage class
C 04: AC 3PH 380V (-15%)–440V (+10%)
06: AC 3PH 520V (-15%)–690V (+10%)
D 3-digit code indicating the rated current. For example, 015 indicates 15 A.
Filter performance
E L: General
H: High-performance
Filter application environment
A: Environment Category I (IEC61800-3), C1 (EN 61800-3)
F
B: Environment Category I (IEC61800-3), C2 (EN 61800-3)
C: Environment Category II (IEC61800-3), C3 (EN 61800-3)
D.8.2 Filter model selection
VFD model
GD350-19-1R5G-4-B
GD350-19-2R2G-4-B
GD350-19-004G-4-B
GD350-19-5R5G-4-B
GD350-19-7R5G-4-B
GD350-19-011G-4-B
GD350-19-015G-4-B
GD350-19-018G-4-B
GD350-19-022G-4-B
GD350-19-030G-4-B
GD350-19-037G-4-B
GD350-19-045G-4-B
GD350-19-055G-4-B
-
FLT P 04
A B
Table D-7 AC 3PH 380V (-15%)–440V(+10%)
Input filter
FLT-P04006L-B
FLT-P04016L-B
FLT-P04032L-B
FLT-P04045L-B
FLT-P04065L-B
FLT-P04100L-B
FLT-P04150L-B
-
045 L
C D E
Description
-500-
Optional peripheral accessories
B
F
Output filter
FLT-L04006L-B
FLT-L04016L-B
FLT-L04032L-B
FLT-L04045L-B
FLT-L04065L-B
FLT-L04100L-B
FLT-L04150L-B
