INVT Goodrive350-19 Series Operation Manual page 360

Goodrive350-19 series VFD for crane
Function
Name
code
Load limit T2 in
stepped speed
P91.28
limit downward
running
Restricted
frequency f2 in
P91.29 stepped speed
limit downward
running
Load limit T3 in
stepped speed
P91.30
limit downward
running
Restricted
frequency f3 in
P91.31 stepped speed
limit downward
running
Enabling
frequency
P91.32
decrease with
voltage
Starting voltage of
frequency
P91.33
decrease with
voltage
Description
current, while closed-loop output torque is
relative to the motor rated torque.)
P91.19, P91.21, P91.23, P91.27, P91.29,
P91.31setting range: 0.00–
P91.24, P91.25 setting range: -20.0%–20.0%
(Open-loop output current is relative to the
motor rated current, while closed-loop output
torque is relative to the motor rated torque.)
Frequency decrease with voltage indicates that
the VFD can automatically decrease the output
frequency to maintain torque output in case of
low line or bus voltage.
Bus voltage
Vdc
Standard bus
voltage
(P91.33*537
+20)V
P91.33*537V
Output
frequency
f
Target
frequency
The following assumes that the target frequency
is set as the rated frequency.
When P91.32=1, if the bus voltage is less than
the starting frequency (Standard bus
-348-
Function parameter list
P00.04
Time t
Time t
Default Modify
○
48.0%
○
75.00Hz
○
25.0%
○
100.00Hz
◎
1
○
85.0%
