Goodrive350-19 series VFD for crane
Function
Name
code
HDIB lower limit
P05.45
frequency
Corresponding
setting of HDIB
P05.46
lower limit
frequency
HDIB upper limit
P05.47
frequency
Corresponding
setting of HDIB
P05.48
upper limit
frequency
HDIB frequency
P05.49
input filter time
AI1 input signal
P05.50
type
P06 group––Output terminals
Function
Name
code
P06.00 HDO output type
P06.01 Y1 output
P06.02 HDO output
P06.03 RO1 output
P06.04 RO2 output
Description
0.000 kHz –
P05.47
-300.0%–300.0%
P05.45–50.000kHz
-300.0%–300.0%
0.000s–10.000s
0: Voltage
1: Current
Note: You can set the AI1 input signal type
through the corresponding function code.
Description
0: Open collector high-speed pulse output. The
max. frequency of pulse is 50.00kHz. For details
about the related functions, see P06.27–P06.31.
1: Open collector output. For details about the
related functions, see P06.02.
0: Disable
1: Running
2: Running forward
3: Running reversely
4: Jogging
5: VFD in fault
6: Frequency level detection FDT1
7: Frequency level detection FDT2
8: Frequency reached
9: Running in zero speed
10: Upper limit frequency reached
-244-
Function parameter list
Default Modify
0.000
○
kHz
○
0.0%
50.000
○
kHz
○
100.0%
○
0.030s
◎
0
Default Modify
◎
0
○
0
○
0
○
1
○
5
