Goodrive350-19 series VFD for crane
Indicator definition:
Indicator
LED1
LED2
LED3
LED4
A.5.4 CANopen communication

communication card (EC-TX511)

The EC-TX505/511 communication card is user-friendly, adopting spring terminals.
3-Pin spring terminal
1 2 3
Terminal resistor switch function description:
Definition
Status indicator
Network connection
status indicator
Network communication
status indicator
Power indicator
card
Pin
1
2
3
This indicator is on when the expansion card is
establishing a connection with the control board;
it blinks periodically after the expansion card is
properly connected to the control board (the period
is 1s, on for 0.5s, and off for the other 0.5s);
and it is off when the expansion card is
disconnected from the control board.
This indicator is on when the physical connection to
the upper computer is normal;
it is off when the upper computer is disconnected.
This indicator is on when there is data exchange
with the upper computer;
it blinks when there is no data exchange with the
upper computer.
This indicator is on after the control board feeds
power to the communication card.
(EC-TX511) and
Function
CANH CANopen bus high level signal
CANG CANopen bus shielding
CANL CANopen bus low level signal
-449-
Expansion card
Function
CAN master/slave
Description
control
