Goodrive350-19 series VFD for crane
Function
Name
code
Input terminal
P05.08
polarity
Digital input filter
P05.09
time
Virtual terminal
P05.10
setting
P05.11 Terminal control Used to set the mode of terminal control.
Description
71: Switch to the master
72: Switch to the slave
73: Enable the VFD
74: Contactor feedback signal
75: Brake feedback signal
76: Operating lever zero-point position
77: Graded reference terminal 1
78: Graded reference terminal 2
79: Graded reference terminal 3
80: Graded reference terminal 4
81: Graded reference terminal 5
82: Upward DEC limit position
83: Downward DEC limit position
84: Light load speed boost signal
85: Brake detection
86: PTC overtemperature valid signal
(supporting only S8 of EC-IO502-00)
87: Reset the position synchronization pulse
counting
88: Switch from motor 1 to motor 3
89: Anti-snag protection input
90: Enable anti-sway
Used to set the polarity of input terminals.
When a bit is 0, the input terminal is positive;
when a bit is 1, the input terminal is negative.
0x000–0x3F
The function code is used to set the filter time for
S1–S4, HDIA, and HDIB. In strong interference
cases, increase the value to avoid maloperation.
0.000–1.000s
0x000–0x3F (0: Disable. 1: Enable)
BIT0: S1 virtual terminal
BIT1: S2 virtual terminal
BIT2: S3 virtual terminal
BIT3: S4 virtual terminal
BIT4: HDIA virtual terminal
BIT5: HDIB virtual terminal
-238-
Function parameter list
Default Modify
○
0x000
○
0.010s
◎
0x00
◎
0
