Goodrive350-19 series VFD for crane
Function
Name
code
Torque reference
P03.13
filter time
Setting source of
forward rotation
P03.14
upper-limit
frequency in
torque control
Setting source of
reverse rotation
P03.15
upper-limit
frequency in
torque control
Forward rotation
upper-limit
P03.16
frequency set
through keypad in
torque control
Reverse rotation
upper-limit
P03.17
frequency set
through keypad in
torque control
Setting source of
electromotive
P03.18
torque upper limit
Description
0.000–10.000s
0: Keypad (P03.16)
1: AI1 (100% corresponding to the max.
frequency)
2: AI2 (same as the above)
3: AI3 (same as the above)
4: Pulse frequency HDIA (same as the above)
5: Multi-step setting (same as the above)
6: Modbus communication (same as the above)
7: PROFIBUS/CANopen/DeviceNet
communication (same as the above)
8: Ethernet communication (same as the above)
9: Pulse frequency HDIB (same as the above)
10: EtherCAT/Profinet communication
11: Programmable expansion card
12: 216 communication
0: Keypad (P03.17)
1–12: Same as those for P03.14
Used to set the frequency upper limits. 100%
corresponds to the max. frequency.
the value when P03.14=1;
when P03.15=1.
Setting range:
0.00Hz–P00.03
frequency)
0: Keypad (P03.20)
1: AI1 (100% corresponding to triple the motor
rated current)
2: AI2
3: AI3
4: Pulse frequency HDIA
-222-
P03.16
sets
P03.17
sets the value
(Max. output
Function parameter list
Default
Modify
○
0.010s
○
0
○
0
○
50.00Hz
○
50.00Hz
○
0
