Goodrive350-19 series VFD for crane
Function
code
for AM 1
Integral coefficient in
P04.43
I/F mode for AM 1
Starting frequency for
P04.44
switching off I/F mode
for AM 1
Enabling I/F mode for
P04.45
Forward current
P04.46
setting in I/F mode for
Proportional
P04.47
coefficient in I/F mode
for AM 2
Integral coefficient in
P04.48
I/F mode for AM 2
Starting frequency for
P04.49
switching off I/F mode
for AM 2
Name
of the output current in closed-loop control.
Setting range: 0–5000
When I/F control is adopted for AM 1, this
parameter is used to set the integral coefficient of
the output current in closed-loop control.
Setting range: 0–5000
When I/F control is adopted for AM 1, this
parameter is used to set the frequency for switching
off the output current in closed-loop control. When
the frequency is lower than the value of this
parameter, the current closed-loop control in the I/F
control mode is enabled;
and when the frequency is higher than that, the
current closed-loop control in the I/F control mode
is disabled.
Setting range: 0.00–20.00 Hz
0: Disable
1: Enable
AM 2
Note: The I/F mode is not applicable to conical
motors.
When I/F control is adopted for AM 2, this
parameter is used to set the output current. The
value is a percentage in relative to the rated current
AM 2
of the motor.
Setting range: 0.0–200.0%
When I/F control is adopted for AM 2, the function
code is used to set the proportional coefficient of
output current in closed-loop control. Setting range:
0–5000
When I/F control is adopted for AM 2, the function
code is used to set the integral coefficient of output
current in closed-loop control. Setting range:
0–5000
When I/F control is adopted for AM 2, this
parameter is used to set the frequency for switching
off the output current in closed-loop control. When
the frequency is lower than the value of this
Description
-152-
Basic operation guidelines
Default
150
10.00Hz
0
120.0%
350
150
10.00Hz
