INVT Goodrive350-19 Series Operation Manual page 162

Goodrive350-19 series VFD for crane
Function
code
threshold of motor 2
P04.26 Energy-saving run
Voltage setting
P04.27
channel
Voltage set through
P04.28
P04.29 Voltage increase time 0.0–3600.0s
Voltage decrease
P04.30
Max. output voltage P04.32 –100.0% (of the motor rated voltage)
P04.31
P04.32 Output min. voltage 0.0%–P04.31 (motor rated voltage)
Weakening coefficient
P04.33 in constant power
Pull-in current 1 in SM
P04.34
V/F control
Pull-in current 2 in SM
P04.35
V/F control
Name
0: Disable
1: Automatic energy-saving run
0: Keypad; Output voltage is determined by P04.28.
1: AI1
2: AI2
3: AI3
4: HDIA
5: Multi-step running
6: PID
7: Modbus communication
8: PROFIBUS/CANopen/DeviceNet
communication
9: Ethernet communication
10: HDIB
11: EtherCAT/Profinet communication
12: Programmable expansion card
13: 216 communication
0.0%–100.0% (of the motor rated voltage)
keypad
0.0–3600.0s
time
1.00–1.30
zone
When the SM VF control mode is enabled, the
function code is used to set the reactive current of
the motor when the output frequency is lower than
the frequency specified by P04.36.
Setting range: -100.0%–+100.0% (of the motor
rated current)
When the SM VF control mode is enabled the
function code is used to set the reactive current of
the motor when the output frequency is greater than
Description
-150-
Basic operation guidelines
Default
0
0
100.0%
5.0s
5.0s
100.0%
0.0%
1.00
20.0%
10.0%
