Goodrive350-19 series VFD for crane
VFD model
GD350-19-220G-4
GD350-19-250G-4
GD350-19-280G-4
GD350-19-315G-4
GD350-19-355G-4
GD350-19-400G-4
GD350-19-450G-4
GD350-19-500G-4
Note:

The rated input voltage drop of input reactors is 2%±15%.

The current adjustment coefficient on the input side of the VFD is higher than 90% after a DC
reactor is configured.

The rated output voltage drop of output reactors is 1%± 15%.

The preceding table describes external accessories. You need to specify the ones you choose
when purchasing accessories.
Table D-6 Reactor model selection for AC 3PH 520V(-15%)–690V(+10%)
VFD model
GD350-19-022G-6
GD350-19-030G-6
GD350-19-037G-6
GD350-19-045G-6
GD350-19-055G-6
GD350-19-075G-6
GD350-19-090G-6
GD350-19-110G-6
GD350-19-132G-6
GD350-19-160G-6
GD350-19-185G-6
GD350-19-200G-6
GD350-19-220G-6
GD350-19-250G-6
GD350-19-280G-6
GD350-19-315G-6
GD350-19-355G-6
GD350-19-400G-6
GD350-19-450G-6
Input reactor
ACL2-280-4
ACL2-280-4
ACL2-280-4
ACL2-350-4
Standard
Standard
Standard
Standard
Input reactor
ACL2-030-6
ACL2-030-6
ACL2-055-6
ACL2-055-6
ACL2-055-6
ACL2-110-6
ACL2-110-6
ACL2-110-6
ACL2-185-6
ACL2-185-6
ACL2-185-6
ACL2-250-6
ACL2-250-6
ACL2-250-6
ACL2-350-6
ACL2-350-6
ACL2-350-6
Standard
Standard
-498-
Optional peripheral accessories
DC reactor
DCL2-280-4
DCL2-280-4
DCL2-280-4
DCL2-315-4
DCL2-400-4
DCL2-400-4
DCL2-500-4
DCL2-500-4
DC reactor
DCL2-030-6
DCL2-030-6
DCL2-055-6
DCL2-055-6
DCL2-055-6
DCL2-110-6
DCL2-110-6
DCL2-110-6
DCL2-185-6
DCL2-185-6
DCL2-185-6
DCL2-250-6
DCL2-250-6
DCL2-250-6
DCL2-350-6
DCL2-350-6
DCL2-350-6
DCL2-400-6
DCL2-560-6
Output reactor
OCL2-280-4
OCL2-280-4
OCL2-280-4
OCL2-350-4
OCL2-350-4
OCL2-400-4
OCL2-500-4
OCL2-500-4
Output reactor
OCL2-030-6
OCL2-030-6
OCL2-055-6
OCL2-055-6
OCL2-055-6
OCL2-110-6
OCL2-110-6
OCL2-110-6
OCL2-185-6
OCL2-185-6
OCL2-185-6
OCL2-250-6
OCL2-250-6
OCL2-250-6
OCL2-350-6
OCL2-350-6
OCL2-350-6
OCL2-400-6
OCL2-560-6
