Goodrive350-19 series VFD for crane
Function
code
P05.01 Function of S1
P05.02 Function of S2
P05.03 Function of S3
P05.04 Function of S4
P05.05 Function of HDIA
P05.06 Function of HDIB
P05.07
P05.08 Input terminal polarity
P05.09 Digital input filter time
P05.10 Virtual terminal setting
P05.11 Terminal control mode
P05.12 S1 switch-on delay
P05.13 S1 switch-off delay
P05.14 S2 switch-on delay
P05.15 S2 switch-off delay
P05.16 S3 switch-on delay
P05.17 S3 switch-off delay
P05.18 S4 switch-on delay
P05.19 S4 switch-off delay
P05.20 HDIA switch-on delay
Name
0: HDIA is high-speed pulse input
1: HDIA is digital input
Tens place: HDIB input type
0: HDIB is high-speed pulse input
1: HDIB is digital input
0–90
Reserved
0x00–0x3F
0.000–1.000s
0x00–0x3F (0: Disable. 1: Enable)
BIT0: S1 virtual terminal
BIT1: S2 virtual terminal
BIT2: S3 virtual terminal
BIT3: S4 virtual terminal
BIT4: HDIA virtual terminal
BIT5: HDIB virtual terminal
0: Two-wire control mode 1
1: Two-wire control mode 2
2: Three-wire control mode 1
3: Three-wire control mode 2
0.000–50.000s
0.000–50.000s
0.000–50.000s
0.000–50.000s
0.000–50.000s
0.000–50.000s
0.000–50.000s
0.000–50.000s
0.000–50.000s
Description
-182-
Basic operation guidelines
Default
1
2
7
0
0
0
0
0x00
0.010s
0x00
0
0.000s
0.000s
0.000s
0.000s
0.000s
0.000s
0.000s
0.000s
0.000s
