INVT Goodrive350-19 Series Operation Manual page 327

Goodrive350-19 series VFD for crane
Function
Name
code
Encoder pulse
P24.18
filter width
Pulse reference
P24.19
filter width
Pulse number of
P24.20
pulse reference
Enabling SM
P24.21 angle
compensation
Frequency point
of speed
P24.22
measurement
mode switchover
Angle
P24.23
compensation
Description
0: Self-adaptive filter
1: Use P24.18 filter parameter
Bit2: Enable/disable encoder frequency-division
output filter
0: No filter
1: Filter
Bit3: Enable/disable pulse reference
frequency-division output filter
0: No filter
1: Filter
Bit4: Enable/disable pulse reference filter
0: No filter
1: Filter
Bit5: Pulse reference filter mode (valid when
Bit4 is set to 1)
0: Self-adaptive filter
1: Use P24.19 filter parameter
Bit6: Frequency-divided output source setting
0: Encoder signals
1: Pulse reference signals
Bit7–15: Reserved
0–63
The filter time is P24.18*0.25μs. The value 0 or
1 indicates 0.25μs.
0–63
The filter time is P24.19*0.25us. The value 0 or
1 indicates 0.25us.
0–65535
0–1
0–630.00Hz
-200.0–200.0%
-315-
Function parameter list
Default Modify
○
2
○
2
◎
1024
○
0
○
1.00Hz
○
100.0%
