Goodrive350-19 series VFD for crane
Function
Name
code
delay
RO1 switch-on
P06.10
delay
RO1 switch-off
P06.11
delay
RO2 switch-on
P06.12
delay
RO2 switch-off
P06.13
delay
P06.14 AO1 output
HDO high-speed
P06.16
pulse output
Description
Y electric level
Invalid
Y valid
Switch on
delay
Setting range: 0.000–50.000s
Note: P06.08 and P06.09
P06.00=1.
0: Running frequency (0–Max. output frequency)
1: Set frequency (0–Max. output frequency)
2: Ramp reference frequency (0–Max. output
frequency)
3: Rotational speed (0–Speed corresponding to
max. output frequency)
4: Output (0–Twice the inverter unit rated
current)
5: Output current (0–Twice the motor rated
current)
6: Output (0–1.5 times the inverter unit rated
voltage)
7: Output power (0–Twice the motor rated
power)
8: Set torque (0–Twice the motor rated torque)
9: Output torque (Actual 0–Twice the motor
rated torque)
10: AI1 input (0–10V/0–20mA)
11: AI2 input (0–10V)
12: AI3 input (0–10V/0–20mA)
13: HDIA input (0.00–50.00kHz)
14: Value 1 set through Modbus communication
(0–1000)
15: Value 2 set through Modbus communication
(0–1000)
16: Value 1 set through
PROFIBUS/CANopen/DeviceNet
communication (0–1000)
17: Value 2 set through
-247-
invalid
Valid
Switch off
delay
are valid only when
Function parameter list
Default Modify
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0
○
0
