General-purpose timer (TIM2)
26.4.7

TIM2 capture/compare mode register 1 [alternate] (TIM2_CCMR1)

Address offset: 0x18
Reset value: 0x0000 0000
The same register can be used for input capture mode (this section) or for output compare
mode (next section). The direction of a channel is defined by configuring the corresponding
CCxS bits. All the other bits of this register have a different function in input and in output
mode.
Input capture mode:
31 30 29
Res. Res. Res. Res.
15 14 13
IC2F[3:0]
rw rw rw
Bits 31:16 Reserved, must be kept at reset value.
Bits 15:12 IC2F[3:0]: Input capture 2 filter
Bits 11:10 IC2PSC[1:0]: Input capture 2 prescaler
Bits 9:8 CC2S[1:0]: Capture/compare 2 selection
This bit-field defines the direction of the channel (input/output) as well as the used input.
00: CC2 channel is configured as output.
01: CC2 channel is configured as input, IC2 is mapped on TI2.
10: CC2 channel is configured as input, IC2 is mapped on TI1.
11: CC2 channel is configured as input, IC2 is mapped on TRC. This mode is working only if
an internal trigger input is selected through TS bit (TIMx_SMCR register)
Note: CC2S bits are writable only when the channel is OFF (CC2E = 0 in TIMx_CCER).
