Low-power universal asynchronous receiver transmitter (LPUART)
1. The LPUART can wake up the device from Stop mode only if the peripheral instance supports the Wakeup from Stop mode
feature. Refer to
Section 36.3: LPUART implementation
2. RXFF flag is asserted if the LPUART receives n+1 data (n being the RXFIFO size): n data in the RXFIFO and 1 data in
LPUART_RDR. In Stop mode, LPUART_RDR is not clocked. As a result, this register is not written and once n data are
received and written in the RXFIFO, the RXFF interrupt is asserted (RXFF flag is not set).
3. When OVRDIS = 0.
36.7
LPUART registers
Refer to
The peripheral registers have to be accessed by words (32 bits).
36.7.1
LPUART control register 1 [alternate] (LPUART_CR1)
Address offset: 0x00
Reset value: 0x0000 0000
The same register can be used in FIFO mode enabled (this section) and FIFO mode
disabled (next section).
FIFO mode enabled
31
30
29
RXF
FIFO
TXFEIE
FIE
EN
rw
rw
rw
15
14
13
Res.
CMIE
MME
rw
rw
Bit 31 RXFFIE:RXFIFO Full interrupt enable
This bit is set and cleared by software.
0: Interrupt is inhibited
1: An LPUART interrupt is generated when RXFF = 1 in the LPUART_ISR register
Bit 30 TXFEIE:TXFIFO empty interrupt enable
This bit is set and cleared by software.
0: Interrupt is inhibited
1: An LPUART interrupt is generated when TXFE = 1 in the LPUART_ISR register
Bit 29 FIFOEN:FIFO mode enable
This bit is set and cleared by software.
0: FIFO mode is disabled.
1: FIFO mode is enabled.
1242/1461
Section 1.2 on page 58
28
27
26
25
M1
Res.
Res.
rw
rw
12
11
10
9
M0
WAKE
PCE
PS
rw
rw
rw
rw
for the list of supported Stop modes.
for a list of abbreviations used in register descriptions.
24
23
22
DEAT[4:0]
rw
rw
rw
8
7
6
TXFN
RXFN
PEIE
TCIE
FIE
rw
rw
rw
RM0453 Rev 1
21
20
19
18
DEDT[4:0]
rw
rw
rw
rw
5
4
3
2
IDLEIE
TE
RE
EIE
rw
rw
rw
rw
RM0453
17
16
rw
rw
1
0
UESM
UE
rw
rw
