RM0453
Bits 31:4 Reserved, must be kept at reset value.
Bits 3:0 TRIGINEN[3:0]: cross trigger event enable/disable
Enables or disables a cross trigger event on each of the four channels when CTITRIGINx is
activated (x = 0 to 7).
0000: Trigger does not generate events on any channel.
XXX1: Trigger n generates events on Channel 0.
XX1X: Trigger n generates events on Channel 1.
X1XX: Trigger n generates events on Channel 2.
1XXX: Trigger n generates events on Channel 3.
CTI trigger out x enable register (CTI_OUTENRx)
Address offset: 0x0A0 + 0x004 * x, (x = 0 to 7)
Reset value: 0x0000 0000
31
30
29
28
Res.
Res.
Res.
Res.
15
14
13
12
Res.
Res.
Res.
Res.
Bits 31:4 Reserved, must be kept at reset value.
Bits 3:0 TRIGOUTEN[3:0]: For each channel, defines whether an event on that channel generates a
trigger on CTITRIGOUTx (x = 0 to 7).
0000: Channel events do not generate triggers on any trigger output.
XXX1: Channel 0 events generate triggers on Trigger output n.
XX1X: Channel 1 events generate triggers on Trigger output n.
X1XX: Channel 2 events generate triggers on Trigger output n.
1XXX: Channel 3 events generate triggers on Trigger output n.
CTI trigger in status register (CTI_TRGISTSR)
Address offset: 0x130
Reset value: 0x0000 0000
31
30
29
28
Res.
Res.
Res.
Res.
15
14
13
12
Res.
Res.
Res.
Res.
27
26
25
24
Res.
Res.
Res.
Res.
11
10
9
8
Res.
Res.
Res.
Res.
27
26
25
24
Res.
Res.
Res.
Res.
11
10
9
8
Res.
Res.
Res.
Res.
RM0453 Rev 1
23
22
21
20
Res.
Res.
Res.
Res.
7
6
5
4
Res.
Res.
Res.
Res.
23
22
21
20
Res.
Res.
Res.
Res.
7
6
5
4
TRIGINSTATUS[7:0]
r
r
r
r
Debug support (DBG)
19
18
17
16
Res.
Res.
Res.
Res.
3
2
1
0
TRIGOUTEN[3:0]
rw
rw
rw
rw
19
18
17
16
Res.
Res.
Res.
Res.
3
2
1
0
r
r
r
r
1371/1461
