Debug support (DBG)
Bits 27:8 Reserved, must be kept at reset value.
Bits 7:4 APBANKSEL[3:0]: AP register bank selection
Selects the 4-word register bank on the active AP for the next transaction.
Bits 3:0 DPBANKSEL[3:0]: DP register bank selection
Selects the register at address 0x4 of the debug port.
0x0: DP_CTRLSTATR
0x1: DP_DLCR
0x2: DP_TARGETIDR
0x3: DP_DLPIDR
0x4 to 0xF: reserved
38.4.9

DP read buffer register (DP_BUFFR)

Address offset: 0x0C
Reset value: 0x0000 0000
31 30 29
r r r
15 14 13
r r r
Bits 31:0 RDBUFF[31:0]: Contains the value returned by the last AP read access.
The value returned by an AP read access can either be obtained using a second read access
to the same address, which initiates a new transaction on the corresponding bus, or else it
can be read from this register, in which case no new AP transaction occurs.
38.4.10

DP target identification register (DP_TARGETSELR)

Address offset: 0x0C
Reset value: 0xXXXX XXXX
31 30 29 28
TINSTANCE[3:0]
w w w w
15 14 13 12
TPARTNO[3:0]
w w w w
