24.4.7

Modular inversion

Modular inversion operation consists in the computation of multiplicative inverse A
If the modulus n is prime, for all values of A (1 ≤ A < n) modular inversion output is valid. If
the modulus n is not prime, A has an inverse only if the largest common divisor between A
and n is 1.
If the operand A is a divisor of the modulus n, the result is a multiple of a factor of n.
Operation instructions for modular inversion are summarized in
Parameters with direction
IN
OUT

Table 150. Modular exponentiation (normal mode)

MODE 0x00
Exponent length (in bits, not null)
Operand length (in bits, not null)
Operand A (base of
(0 ≤ A < n)
exponentiation)
Exponent e (0 ≤ e < n)
Modulus value n (Odd integer only, n < 2
e
Result: A mod n (0 ≤ result < n)

Table 151. Modular exponentiation (fast mode)

MODE 0x02
Exponent length (in bits, not null)
Operand length (in bits, not null)
Operand A (base of
(0 ≤ A < n)
exponentiation)
Exponent e (0 ≤ e < n)
Modulus value n (Odd integer only, n < 2
Montgomery param
(mandatory)
R2 mod n
e
Result: A mod n (0 ≤ result < n)

Table 152. Modular inversion

MODE 0x08
Operand length (In bits, not null)
Operand A (0 ≤ A < n)
Modulus value n (Odd integer only, n < 2
-1
Result: A mod n 0 < result < n
Value (Note)
3136
Value (Note)
3136
Value (Note)
3136
